Hioki;AC Grounding HiTester;3157-01;earth, field;
@
Hioki 3157-01- Protective grounding checks
- Ground connection tracing of machine tools and wiring panels
- High-current behavior evaluation;
Hioki;AC m-ohm HiTester;3560;Component, Milliohm Tester;
@
Hioki 3560- Low-power resistance measurement
- Measure Battery voltage
- High-resolution measuring;
Hioki;AC Voltage Logger;3637-20;Environmental, data logger;
@
Hioki 3637-20- Recording and Monitoring fluctuation in power supply
- Measure AC voltage
- Range: 600.0 V AC;
Hioki;AC withstanding voltage of the electric appliances;3173;field;
@
Hioki 3173- Measure between 0 to 3kV AC
- Timer Function (Setting range: 1 to 99 sec)
- Compact, Lightweight;
Hioki;AC withstanding voltage Tester;3158;field;
@
Hioki 3158- Voltage enduring test AC: 0 to 2.5kV/5.0 kV, 500 VA & 0.01 to 120.0 mA
- Stores 20 sets of test conditions
- Zero-V switching
- Electrical Discharge function;
Hioki;AC/DC Power HiTester;3334;current;
@
Hioki 3334, 3334-01- DC, AC, AC+DC Measurement
- Complete Accuracy over a Input Range 1.00mA~30.00A, 0.150V~300.0V, 0.0000W~9.000kW;
Hioki;Automatic Insulation / Withstanding HiTester;3153;field;
@
Hioki 3153- Insulation and AC/DC continuous voltage withstand testing
- Stores 10 sets test conditions (each for insulation and voltage)
- 0.2kV to 5.00kV AC, 500VA(max 30 mins)
- 0.2kV to 5.00kV DC, 50VA(continuance);
Hioki;Battery HiTester;3554,3555,3561;component tester;
@
Hioki 3554- Auto-Hold and Auto-Memo function
- Measure up to 60 volts
- Stores up to 4800 sets of data
- Enhanced noise immunity
Hioki 3555- Support for high-capacity batteries
- For compact storage batteries (portable telephone)
- Simultaneously measure resistance and voltage
Hioki 3561- High speed and reliable battery inspection
- High precision accuracy
- Perfect Battery tester for Production Line;
Hioki;C HiTester;3504-40, 3504-50, 3504-60, 3505, 3506;component tester, Capacitance;
@
Hioki 3504-40, 3504-50, 3504-60, 3505, 3506- High speed measurement of 2ms
- Large-capacitance MLCC Inspection with Constant Voltage
- Model 3504-60 can detect contact failure on all 4 terminals
- Model 3504-40 perfect for inegrating into taping machines
- BIN function on 3504-60/50 is ideal for sorting machines
- Model 3505/3506 ideal for production line with enhanced repeatability measurement accuracy and self-calibration function;
Hioki;Can Adapter;8910;Environmental, CAN-Bus signals Recorder;
@
Hioki 8910- Select CAN-Bus information and convert them into analog/logic signals to your recorder or data logger
- Up to 12ch analog output + 24bit logic output
- Record both CAN adapter analog output and actual analog data simultaneously;
Hioki;Capacitance HiTester ;3501;component tester, LCR;
@
Hioki 3501- One-touch key operation
- Measure capacity with DC
- Measure polar capacitors without bias;
Hioki;Card HiTester;3244;voltage, resistance, field;
@
Hioki 3244- Only 9.5mm thick and 60 g, 4199 count display and auto power saving function
- DC Voltage Range: 420 mV to 500 V, 5 ranges
- AC Voltage range: 4.2V to 500V, 4 ranges
- Resistance range: 420 ohm to 42 M-ohm, 6 ranges;
Hioki;Clamp Logger;3636-20;Environmental, data logger;
@
Hioki 3636-20- Up to 32,000 measurements data can be collected with optional 3911-20 for processing by PC
-Effective value rectifier method
- AC current;
Hioki;Clamp On AC/DC HiTester;3287, 3288, 3290, 3290-10;current, clamp meter;
@
Hioki 3287, 3288- AC Voltage range: 4.200 to 600V AC, 4 ranges
- DC Voltage range: 420.0mV to 600 V DC, 5 ranges
- Resistance: 420.0 to 42.00 M-ohm
- Model 3287 is ideal to handle cogenerator/invertor energy-saving equipment. AC/DC Current range: 10.00 or 100.0 A AC, 2 ranges
- Model 3288 is ideal for high current measurment such as UPS emergency batteries and train motors. AC/DC Current range: 100.0 or 1000A AC, 2 ranges
-
Hioki 3290, 3290-10- AC/DC Current ranges: 20 to 100A, 20 to 200A, 200 to 2000A
- current distortion, full/half-wave rectification, peak value of inrush current, battery measurement;
Hioki;Clamp On Adaptor, AC only;9290-10;conversion adapter, clamp meter, current;
@
Hioki 9290-10- AC current up to 1500A, secondary current 1/10 of primary
- 55 mm(2.17 in) dia or 88mm(3.15 in) width;
Hioki;Clamp On HiTester, AC-current;3127-10, 3128-10, 3280-10, 3280-20, 3291;clamp meter;
@
Hioki 3127-10- Drop-proof "tested-tough"
- Temperature:-50 to 200@o@C
- Resistance:1 k or 100 k-ohm
- With range of 300A
Hioki 3128-10- Drop-proof "tested-tough"
- Temperature:-50 to 200@o@C
- Resistance:1 k or 100 k-ohm
- With range of 1500A
Hioki 3280-10, 3280-20- Model 3280-10, 1000A, clamp aperture: 33mm dia
- Model 3280-20, 1000 A rms, clamp aperture: 33mm dia
- Light 100g
- AC Current range: 42.00 to 1000 A AC
- AC/DC Volt range: 4.200 to 600 V AC/DC
Hioki 3291- Flip display to see measurement reading from any angle
- Max. 1000A, TRMS
- Filter out high frequency noises for a clean signal;
Hioki;Clamp On Leak HiTester, AC only;3283, 3293;leak current meter;
@
Hioki 3283- Wide bandwidth, 5Hz to 15kHz (Waveform output)
- AC Current range: 10.00 mA to 200 A AC
- Frequency range: 100.0 or 1000 Hz
- TRMS, Analyzer functions for filering and output signals
Hioki 3293- Measure leakage current and load
- Flip display to see measurement reading from any angle
- AC current: 30.00m/300.0m/6.000/60.00/600.0/1000A, 45Hz to 400Hz, TRMS rectified;
Hioki;Clamp On Power HiTester;3169-20, 3169-21, 3286-20;phase angle, phase detection, harmonic level, Hz, Voltage, PF, 3-phase, single-phase;
@
Hioki 3129-20, 3129-21- Measure Single-phase 2-wire, single-phase 30-wired, three-phase 3-wire, three-phase 4-wire system (50/60 Hz)
- Power recording for individual waveforms
- 5A to 5000A range, PC card data storage
- Simultaneous recording of demand values and harmonics
- Model 3169-21, D/A output
Hioki 3286-20- Single-phase/two-wires, Three-phase/three-wires(balanced load only)
- Measure voltage/current peak, effective/reactive/apparent power, power factor, phase angle, frequency, volt/current harmonic levels(up to 20th)
- External output of data to PC;
Hioki;Clamp on Probe (For oscilloscope/memory hicorder);3273-50, 3274, 3275, 3276;Clamp Sensor;
@
Hioki 3273-50, 3276- Model 3273-50: DC to 50 MHz(-3dB)
- Model 3276: DC to 100MHz(-3dB)
- 30A, Noise level: 2.5mA max
- 300 V CAT I (insulated wire)
Hioki 3274, 3275- Model 3274:DC to 10MHz(-3dB), 150A
- Model 3275: DC to 2MHz(-3dB), 500A rms
- Noise level: 25mA rms max
- 600V CAT II, 300V CAT III(insulated wire);
Hioki;Clamp on Sensor/Sensor Unit (use with power meter or memory hicorder);9555-10, 9272-10, 9277, 9278, 9279, 9709;Clamp Sensor, current;
@
Hioki 9272-10- 20A AC, 200A AC
- 5Hz to 10kHz
- 600V AC rms(insulated wire)
- Sensor unit 9555-10 required
Hioki 9277, 9278- Model 9727: 20A AC/DC
- Model 9728: 200A AC/DC
- DC to 100kHz(@plusminus@5% f.s.)
- 600V peak(insulated wire)
- Sensor unit 9555-10 required
Hioki 9279- 500A AC/DC
- DC to 20kHz(@plusminus@5% f.s.)
- 600V peak(insulated wire), 2V/rated current range
- Sensor unit 9555-10 required
Hioki 9709- 500A AC/DC(continuous 700A)
- DC to 100kHz, 1000V AC/DC
- Sensor unit 9555 required
Hioki 9555-10- @plusminus@12V @plusminus@0.5V
- Compatible model: 9272-10/9277/9278/9279/9709
- Power supply for current probes;
Hioki;Communication Base;3911-20, 3912-20;recorder;
@
Hioki 3911- Recording Capacity: Max 16,000 data points x 16ch, 32,000 data points x 8ch
- Infrared Optical Communications, RS-232C
- Logger to the 3911-20: 500data/s, 3911-20 to PC: 19200bps
Hioki 3912-20- Recording Capacity: Max 16,000 data points x 16ch, 32,000 data points x 8ch
- Infrared Optical Communications, USB 1.1
- Logger to the 3912-20: 250data/s, 33912-20 to a PC: 12Mbps;
Hioki;Current Transformer;CT-2MR;current;
@
Hioki CT-2MR- Rated voltage: 100A, 120A, 150A, 200A, 250A, 300A, 500A, 600A
- Raged load: 2VA
- Secondary current: 5A
- Conductor volt rating: 1150 V AC;
Hioki;DC Signal Source;7011;power supply, current;
@
Hioki 7011- Check thermocouple temperature sensors
- Generate various signals for electronic circuit and equipment testing (constant volt and current)
- Calibrate industrial equipment all with a single unit;
Hioki;Digital Clamp On HiTester, AC/DC current;3281, 3282, 3284, 3285;clamp meter;
@
Hioki 3281- AC Current range: 30.00 to 600 A AC, 30.0 to 300 A peak
- AC Voltage range 300.0 or 600 V AC, up to 300 or 600 V peak
- Wave peak value, Waveform distortion check
- Non-fuse type protects up to 600 V AC
Hioki 3282- AC Current range: 30.00 to 1000 A AC, 30.0 to 600 A peak
- AC Voltage range: 300.0 or 600 V AC, up to 300 or 600 V peak
- Wave peak value, Waveform distortion check
- Non-fuse type protect up to 600 V AC
Hioki 3284, 3285- Model 3284, 200 Arms, clamp aperture: 33mm dia
- Model 3285, 2000 Arms, clamp aperture: 55mm dia.
- Inrush current crest value
- RMS value of full-wave rectified waveforms
- Waveform and harmonic analysis;
Hioki;Digital HiTester;3237, 3238, 3239, 3255, 3256, 3801, 3802, 3803, 3804;handheld true RMS Digital Multimeter, Digital Multi meter, component;
@
Hioki 3237/3237-01, 3238/3238-01, 3239/3239-01- DC Voltage range: 200 mV to 1000 V
- AC Voltage range: 2000 mV to 700 V
- Samples at rate up to 300 samples/sec
- Comparator function provides hig-speed pass/fail evaluation
- Model 3238/3238-01/3239/3239-01, AC/DC current range: 200mA or 2000mA and frequency range: 100Hz to 300 kHz
Hioki 3255- DC Voltage range: 420mV to 1000V
- AC Voltage range: 420mV to 100V
- AC Current range: 10.00A to 1000A
- Dust-proff and water-proof, polarized terminal design
Hioki 3256- DC/AV Voltage: 420.0mv to 1000V
- DC/AC Current 42.00 @m@A to 420.0mA
- Resistance: 420.0 ohm to 42.00 M ohm
Hioki 3801, 3802- DC/AV/AC+DC Voltage: 51.000mV to 1000.0V
- DC/AC/AC+DC current: 510.00 @m@A to 10.000A
- Model 3802 do not have AC+DC voltage/current
Hioki 3803, 3804- Model 3803, DC/AV Voltage: 399.9mV to 1000V, Resistance 399.9ohm to 39.99Mohm, DC/AC Current: 399.9@m@ to 10.00A
- Model 3804, DC/AC Voltage: 999.9mV to 999.9V, Resistance: 400.0 ohm to 40.00 M-ohm, DC/AC Current: 400.0@m@A to 10.00A;
Hioki;Digital m-ohm HiTester;3154;field, Insultation tester;
@
Hioki 3154- Measure insultaion resistance
- Testing Voltage: 25 to 50V: 2 Mohm to 200 Mohm, 100 to 500V: 2 Mohm to 2000 Mohm, 1000V: 2 Mohm to 4000 Mohm
- Fast Sampling rate: 10 samples/s;
Hioki;Digital M-ohm HiTester;3453, 3454-10, 3454-11, 3454-51;field, insulation tester;
@
Hioki 3453- DC voltage range: 125, 250, 500, 1000 V range
- Insulation Measurement through sight and sound
- Memorizes up to 20 data points
- Low resistance: 0 to 400.0 ohm
Hioki 3454-10, 3454-11, 3454-51- Model 3454-11/-51, DC Voltage range: 250, 500, 1000 V DC
- Model 3454/10, DC Voltage range: 50, 125, 250, 500 V DC
- Low resistance(continuity): 40.00ohm to 4.000 Mohm;
Hioki;(Solar HiTester) Digital MultiMeter;3245;component;
@
Hioki 3245- Hybrid power system incorporates both a solar-charged main battery and a backup battery
- Vest-pocket sized cAT III conformance
- DC Voltage range: 420mV to 600V, AC Voltage range: 4.2V to 600V, Frequency: 50 to 500Hz, Resistance range: 420ohm to 42M-ohm
- Light meter function;
Hioki;Digital Printer;9203; ;
@
Hioki 9203- Compatible model: 3227, 3540, 3560, 3550, 3551
- Interval printing, manual printing, calculation, histogram, graph printing;
Hioki;Digital ultra-insulation/micro ammeter 1-ch/4ch;DSM-8104(1-ch), DSM-8542(4-ch);field;
@
Hioki 8104- Voltage: DC 0.1 - 1,000V
- Resistance: 100@m@A - 10pA
- Measure insulation resistance of capacitive/highly speed
- Histogram display;
Hioki;Earth HiTester;3143, 3151;field;
@
Hioki 3143- Ground resistance: 20.0 to 49.9 ohm, 50.0 to 500.0 ohm
- Open circuit voltage: 0.9 V ACpeak type, Testing current: 3.6 mA AC max with terminals shorted, Testing frequency: 100 kHz to 1.5 MHz
Hioki 3151- Ground resistance: 10 ohm, 100 ohm, 1000 ohm
- Ground voltage: 0 to 30V, Open circuit voltage: 50 V AC max
- Electrical/mesh/Electrical power equipment grounding;
Hioki;External Multiplier;HB-1; ;
Hioki HB-1- Rated voltage: 500V, 750V
- Rating 1mA;
Hioki;External Shunts;HS-1; ;
Hioki HS-1- Rated current: 30A, 50A, 75A, 100A, 150A, 200A, 300A
- Rating: 50mV;
Hioki;Flat-bed recorder;FBR-251A(1pen), FBR-253A(3pen);Environmental,logger ;
@
Hioki FBR-251A(1pen), FBR-253A(3pen)- Recording results of analytical instruments
- Input: 0-50mV/0-100V F.S (16ranges)
- Simultaneous chart feeding by external signal available;
Hioki;High performance portable recorder;EPR-3511,EPR-3531;Environmental, logger;
@
Hioki EPR-3511(1pen), EPR-3531(3pen)- Recording width: 150mm
- Input: @plusminus@ 0.5 - 250mV & V F.S. (18ranges)
- Low power consumption design;
Hioki;High sensitivity recorder;EPR-10B;Environmental, logger;
@
Hioki EPR-10B(1pen)- Compact, light-weight and inexpensive
- Recording width: 150mm
- Input : @plusminus@ 0.5 - 50mV / @plusminus@ 0.25 - 1V F.S. (5ranges);
Hioki;HiTester;3008,3030-10;Analog Multimeter, Multi meter, multi tester;
@
Hioki 3008- For high power lines with fuse protect up to 50,000A and 10 ohm resistor
- DC/AC Voltage range: 6/30/60/300/600V @plusminus@2.5 % f.s.
Hioki 3030-10- DC Voltage range: 0.3V(16.7 k-ohm/V), 3/12/30/120/300/600V (20k-ohm/V)
- AC Voltage range: 12V (9k-ohm/V), 30/120/300/600V (9 k-ohm/V)
- DC current range: 60 @m@A/30 m/300 mA;
Hioki;Humidity Logger;3641-20;Environmental, data logger;
@
Hioki 3641-20- Temperature: -20.0@o@C to 70.0@o@C (internal sensor), -40.0@o@C to 180.0@o@C (external sensor)
- Humidity: 0.0 % to 100.0 % rh
- Data memory: 8000 data x 2ch
- Recording interval: 2 to 30 sec, 1 to 60 min, 14 settings;
Hioki;Instrumentation Logger;3634-20;Environmental, data logger;
@
Hioki 3634-20- Instrumentation range: 0.00 to 20.00 mA
- Data memory: 16000 data (60min interval, total 667 days)
- Recording interval 2 to 30 sec, 1 to 60 min, 14 settings
- Input channel: 1;
Hioki;Insulation / Withstanding HiTester;3159;field;
@
Hioki 3159- Testing voltage: 0 to 2.5 kV/0 to 5.0 kV AC, dual-range configuration, 500VA
- Current: 0.01 mA to 120 mA @plusminus@(3 % f.s. +20@m@A), 2mA/8 mA/32 mA/120 mA AC
- Insulation testing voltage: 2 m-ohm to 2000 m-ohm(500V DC), 4m-ohm to 2000 m-ohm(1000V DC)
- Stores up to 10 sets of test conditions;
Hioki;High Voltage Insulation HiTester;3455;field;
@
Hioki 3455- Measure insulatin resistance in high-voltge facilities such as motors, transformers and power cable
- Complies with safety regulation for Category III(1 kV) and Category IV (600V) measurements
- Storage funtion for 100 data set, Logging function for max 10 log files with 360 data set each;
Hioki;Lan Cable HiTester;3665-20;telecommunication;
@
Hioki 3665-20- Measureable cable: Twisted-pair cable, 100ohm characteristic impedance shielded/unshielded, CAT 3,4,5,5e,6
- Detectable errors: open, short, reversed, transposed, split pairs and other miswiring
- Measurable lengths: 2 to 300m, 6.6 to 984 ft;
Hioki;Laser Light Source;3662-20, 3663-20;telecommunication;
@
Hioki 3662-20, 3663-20- laser diode
- Output connector: FC, SC
- Output wavelength: 1310@plusminus@20nm, 1550@plusminus@20nm
- Spectrum width: 5nm max
- Output level -6@plusminus@2 dBm;
Hioki;LCR HiTester;3511-50, 3522-50, 3532-50, 3535;component tester;
@
Hioki 3511-50- Measurement parameters: |Z|,R: 10 m-ohm to 200.00 m-ohm, phase angle: -90.00 to +90.00 @o@, C: 0.940 pF to 999.99mF, L: 1.600@m@H to 200.00kH, D: 0.0001 to 1.9900, Q: 0.85 to999.99
- Source voltage: 50mV to 1 V rms, Source frequency: 120 Hz or 1 kHz
Hioki 3522-50, 3532-50- Measurement parameters: |Z|,R,X: 10.00mohm to 200Mohm, |Y|,G,B: 5.0000ns to 99.999S, Phase angle : -180.00@o@ to +180.00@o@, C: 0.3200 pF to 1.0000 F, L: 16.000nH to 750.00kH, D:0.00001 to 9.99999, Q: 0.01 to 999.99
- Model 3522, DC Source frequency: 1mHz to 100kHz
- Model 3532, Source frequency: 42Hz to 5MHz
Hioki 3535- Measurement parameters: |Z|, R: 100mohm to 2kohm, 1kohm to 20kohm, 10kohm to 300kohm, C: 0.66pF to 15.9@m@F, 0.066pF to 1.59nF, 4.4fF to 159pF, L: 0.133nH to 3.18mH, 1.33@m@H to 31.8mH, 13.3@m@H to 477mH, phase angle: -180.00@o@ to 180.00@o@
- Source frequency: 100kHz to 120MHz;
Hioki;Leak Current HiTester;3156;current;
@
Hioki 3156- Measure mode: Earth leakage current, Patient leakage currrent I, II & III/Patient auxilliary current, Leakage current between enclosure and earth, line or enclosure
- DC/AC/AC+DC mode: 50@m@A/500@m@A/5mA/25mA, AC peak mode: 500@m@A/1mA/10mA/75mA
- Stores data for 100 units;
Hioki;Line Splitter, AC only;CT-101A;Conversion Adapter, clamp meter;
@
Hioki CT-101A- 0 to 15A AC (50/60 Hz, continuous use)
- 1:1 or 10 times of primary
- Rated circuit voltage: 100 V AC rms;
Hioki;LUX HiTester;3423;lux meter, Environmental, data logger, light;
@
Hioki 3423- Light intensity: 20 to 200,000 lx full-scale, 5 ranges
- Response time: 5sec or less(auto range), 2 sec or less (manual range);
Hioki;LUX Logger;3640-20;lux meter, Environmental, light meter;
@
Hioki 3640-20- Light intensity: 0 to 2000lx/20000lx/200000lx, Manual range(Select when recording is stopped)
- Data Memory: 32000data x 1ch(1-min interval, total 22 days)
- Recording interval: 1 to 30 sec, 1 to 60min, 15 settings;
Hioki;Magnetic Field HiTester;3470;Environmental, EMF tester;
@
Hioki 3470- Magnetic flux density: 2.000@m@T/20.00@m@T/200.0@m@T/2.000mT
- Exposure level: 20.00%/200.0%/2000%
- Output: 200mV/f.s.(for single axis of each range), 3-axis waveform, RMS;
Hioki;Memory Hicorder PartI;8807-01, 8807-51, 8808-01, 8808-51, 8826, 8835-01, 8847;Environmental, Data Acquisition, RMS Recording, memory recorder, logger;
@
Hioki 8807-01(2 analog ch), 8808-01(4 analog ch)- 10mV to 100V/division, 450V rms, 200@m@s to5min/division
- Frequency: DC to 50kHz@plusminus@3 dB
Hioki 8807-51, 8808-51- Measure harmonics up to 40 orders from fundamental wave
- Anaysis display includes RMS value, content factor, phase angle, active/reactive/apparent power, power phase angle for each order of harmonics (numeric and graphic display)
Hioki 8826- 5mV to 20V/division, 100@m@s to 5min/division, resolution:1/80 of range, 335V rms
- DC to 400kHz@plusminus@3dB
- Simultaneous sampling, display and recording
Hioki 8835-01- 10mV to 50V/division, 280Vrms, 100@m@s to 5 min/division
- DC to 400kHz@plusminus@3 dB
- Compact 4/8ch recorder saves space with slim profile
Hioki 8847- High-speed sampling up to 20MS/s with fully isolated inputs
- 16 analog + 16 logic ch to 64 logic + 10 analog ch
- 400 VDC, DC to 5MHz, DC to 100kHz;
Hioki;Memory Hicorder PartII;8855, 8860-50, 8861-50, 8870-20;Environmental, Data Acquisition, RMS Recording, memory recorder, logger;
@
Hioki 8855- 5mV to 20V/division, 280V rms, 5@m@s to 5 min/division, resolution: 1/400 of range
- Max 512M words long storge memory
- Analog (8 ch) + logic (16 ch)
Hioki 8860-50, 8861-50- Model 8860-50, Input units: 4, Max. 16 Analog ch + 16 logic ch
- Model 8861-50, Input units: 8, Max. 32 analog ch + 16 logic ch
- 5mV to 20V/div, resolution: 1/100 of range
- Various interface built-in: LAN/USB/PC-card slot
Hioki 8870-20- Palm size, high speed recording at 1 MS/s, sharp wide QVGA-TFT LCD screen
- 2 analog ch + 4 logic ch
- 10mV to 50V/div, resolution: 1/100 of range, DC 400V, 100@m@s to 5min/div
- Frequency: DC to 50kHz(-3dB);
Hioki;Memory HiLOGGER;8420-51, 8421-51, 8422-51, 8423;data logger, Environmental;
@
Hioki 8420-51(8ch), 8421-51(16ch), 8422-51(32ch)- Measure temperature, voltage, humidity(with optional sensor), cumulative pulses, rotations
- Thermocouple types: K, E, J, T, N,W(WRe5-26), R, S and B
- 100mV, 1V, 10V, 100V and 1-5Vf.s.
- Memory capacity: Internal-32MB, External- up to 1G
-Attachable Printer and I/O Module
Hioki 8423- Votage/Temp Unit 8948, Voltage:@plusminus@150mV to@plusminus@100V, 1-5V f.s., Max resolution:5@m@V, Temperature: -200@o@C to 2000@o@C (K,E,J,T,N,W(Wre5-26),R,S,B), DC 100V, 200V DC, 600V DC/AC
- Universal Unit 8949, Voltage: @plusminus@150mV to @plusminus@60V, 1-5f.s., Temperature: -200@o@C to 2000@o@C(K,E,J,T,N,W(Wre5-26),R,S,B), Humidity: 100%rh f.s., DC 60V, 120V DC, 600V DC/AC
- Digital/Pulse Unit 8996, Totaliized pulses: 0 to 1000M pulse, Rotation count: 0 to 5000/n(r/s)f.s, DC 50V, 33V AC, 70V DC, 600V DC/AC
- Recording: 10ms to 1hr, saved to CF Card in real time, Trigger function, Digital filter, FTP/HTTP server function;
Hioki;Meter Relay;2103; ;
@
Hioki 2103- Ultra sensitive 1@m@A, 10 mV DC movement
- Relay action delays circuit closure upon power on
- Power supply: 100 or 200 VAC @plusminus@ 10%;
Hioki;Micro Hicorder (TRMS Volt & Current recorder);8205-10, 8206-10;Environmental, Data Acquisition, memory recorder, harmonic analysis, logger;
@
Hioki 8205-10, 8206-10- Model 8205-10, DC/AC Voltage: 0.1V to 500Vf.s., AC/DC voltage range: +0.5 dB to -3 dB from 20 Hz to 30 kHz
- Model 8206-10, AC Votage: 100/200/500Vf.s, AC/DC voltage range: +0.5dB to -3dB from 30 Hz to 30kHz
- TRMS rectification system to read distorted waveform, sampling rate: 100 samples/sec with selectable chart speeds;
Hioki;M-ohm HiTester;3118-11, 3118-12, 3451-11, 3451-12, 3451-13, 3451-14, 3451-15 3452-11, 3452-12, 3452-13;component tester;
@
Hioki 3118-11, 3118-12- Model 3118-11: 250VDC, 50M-ohm, scale indication at 0.05Mohm to 20Mohm
- Model 3118-11: 500VDC, 100M-ohm, scale indication at 0.1Mohm to 50Mohm
- Model 3118-12: 1000VDC, 2000M-ohm, scale indication at 2Mohm to 500Mohm
- Model 3118-12: 500VDC, 200M-ohm, scale indication at 0.1Mohm to 50Mohm
- Discharge function, AC voltage scale 0 to 600V(50/60Hz)@plusminus@7%f.s.,
First effective measurement range and tolerances @plusminus@5%
Hioki 3451-11, 3451-12, 3451-13, 3451-14, 3451-15- Model 3451-11: 125VDC, 20M-ohm, scale indication at 0.02Mohm to 10Mohm, AC voltage scale 0 to 250V
- Model 3451-12: 250VDC, 50Mohm, scale indication at 0.05Mohm to 20Mohm, AC voltage scale 0 to 300V
- Model 3451-13: 500VDC, 100Mohm, scale indication at 0.1Mohm to 50Mohm, AC voltage scale 0 to 500V
- Model 3451-14: 500VDC, 1000Mohm, scale indication at 1Mohm to 500Mohm, AC voltage scale 0 to 500V
- Model 3451-15: 1000VDC, 2000Mohm, scale indication at 2Mohm to 1000Mohm, AC voltage scale 0 to 500V
Hioki 3452-11, 3452-12, 3452-13- Lightweight: 420g, Live line check & low battery check function
- Model 3452-11: 25/50/100VDC, 10/20Mohm, scale indication at 0.01Mohm to 5Mohm/0.02Mohm to 10Mohm, AC voltage scale 0 to 150V
Model 3452-12: 125/250/500VDC, 20/50/100Mohm, scale indication at 0.02Mohm to 10Mohm/0.05Mohm to 20Mohm/0.1Mohm to 50Mohm, AC voltage scale 0 to 500V
- Model 3452-13: 250/500/1000VDC, 50Mohm/100Mohm/2000Mohm, scale indication of 0.05Mohm to 20Mohm/0.1Mohm to 50Mohm/2Mohm to 1000Mohm, AC voltage scale 0 to 500V;
Hioki;m-ohm HiTester, DC source;3540;component tester, Milliohm Tester;
@
Hioki 3540- 30 m-ohm to 30 k-ohm, 3500 full digits
- 100mA to 10@m@A, 3.5mV DC to 350mV DC
- 4 terminal method, comparator function memorizes up to 7 tables
- temperature compensation function, calculates value relative to copper at 20@o@C/68@o@F;
Hioki;Motor / Harmonic HiTester;3194;Power, rotation, speed, torque, Single-phase to 3-phase;
@
Hioki 3194- Single-phase/2-wires to 3-phase/4-wires
- Measure voltage, current, volt/current peak, effective/reactive/apparent power, power factor, phase, frequency, current/power integration, load rate, efficiency harmonic(up to 3000th order), waveform, torque, RPM, motor output
- Voltage: 6.0000V to 1.0000kV;
Hioki;Noise HiLogger;3145;environmental, data logger, telecommunication, power, sound;
@
Hioki 3145- Measure noise level and frequencies on telecom, power, grounding lines
- BNC (max. input voltage 5V peak), 5kHz to 100MHz(-3dB)
- Current: 0.2mA, 2A, 20A, Voltage: 10mV, 100mV, 1V
- Center frequency: 15k, 70k, 250k, 1M, 5M, 20M, 60MHz, 7 BPFs separtes noise(fixed), measure peak value;
Hioki;Noise Search Tester;3144-20;telecommunication, power, sound;
@
Hioki 3144- Identify noise in communication and power lines
- Non-contact type voltage sensor
- frequency: 500Hz to 30MHz, separated into 7 ranges(-3dB range)
- x1 range 0dBV(1V)f.s.(0 dBV to -30 dBV), x10 range -20dBV(0.1V)f.s. (-20dBV to -50 dBV);
Hioki;Optical Power Meter ;3661-20, 3664;telecommunication;
@
Hioki 3661-20- Measure absolute value of input optical power, optical loss, auto compare measured power with previously input, reference value to calculate and display loss
- Calibration wavelength: 850nm, 1310nm, 1550nm
- Range: -60dBm to +9dBm
- Memory: Max. 1000 data per wavelength
Hioki 3664- Optical power measure in nW, @m@W, mW, dBm, dB
- Automatic compensation for sensor's sensitivity
- Max. 10 wavelengths preset
- Wavelength: 320nm to 1100nm, Power: -59dBm to +17dBm, Max rated power: 50mW(+17dBm);
Hioki;Pencil HiTester (Digital Multimeter);3246;component;
@
Hioki 3246- Penlight brightly illuminates test points, full-auto raning 4199 count display
- DC Voltage range: 420.0mV to 600V, 5 ranges
- AC Voltage range: 4.200V to 600V, 4 ranges
- Resistance range: 420.0ohm to 42.00M-ohm, 6 ranges
- Safety: EN61010, overvoltage category III 600V, EMC: EN61326;
Hioki;Personal recorder (Megohm checker);PHOENIX PRR-5011, PRR-5021;Environmental, logger, ohm, component;
@
Hioki PRR-5011 (1pen), PRR-5021 (2pen)- Super Mohm Checker & Chart Recorder
- Inexpensive, auto-pen rest & semi auto loading funtions
- Recording width: 250mm, Recording roll paper: 45m
- Input: @plusminus@0.5 - 250mV & V F.S. (18 ranges);
Hioki;Phase Detector;3126-01, 3129-10;field;
@
Hioki 3126-01- Voltage range: 110 to 480VAC
- Frequency: 40 to 70Hz
- Continuous/110VAC, 30 min/220VAC, 4min/480VAC
Hioki 3129-10- CATIV 600V/CATIII 1000V Safe
- Voltage Range: 70 to 1000VAC (50/60Hz)(sine wave, continuous input)
- Live Wire Check: R-S and S-T lamps will light if voltage between wires are within voltage range
- Phase Detection: Positive (4 LEDs lit in clockwise order and 3 short beeps), Negative (4 LEDs lit in counterclockwise order and 1 continusous beep);
Hioki;Portable Recorder (Megohm checker & ChartRecorder);EPR-3011, EPR-3021;Environmental, logger;
@
Hioki EPR-3011(1pen), EPR-3021(2pen)- Inexpensive, compact and light-weight
- Input: @plusminus@0.5 - 250mV, @plusminus@0.5 - 25V F.S. (12 ranges)
- Low power consumption design;
Hioki;Power Hicorder;8715;Environmental, Data Acquisition, memory recorder, current, logger;
@
Hioki 8715- 100V/200V/400V AC line, 200@m@s to 20ms/division, 7 settings (1 div=80samples)
- Power waveform observation, RMS fluctuation measurement
- Memory: 64k words/ch, TypeII PC card slot(9726/9727/9728/9729 PC card, 128MB to 1GB);
Hioki;Power HiTester;3193, 3331, 3332, 3333, 3333-01;current, phase angle, Hz, PF, Single-phase to 3-phase 3-wire;
@
Hioki 3193- Measure voltage, current, voltage/current peak, effective/reactive/apparent power, power factor, phase, frequency, current/power integration, load rate, efficiency voltage,torque, RPM, frequency, motor output, harmonic, waveform, volt fluctuation/flicker
- Single-phase/2-wired to 3-phase/4wired
- Volt:6.0000V to 1.0000kV, Current: 200.00mA to 500.00A, 5VDC f.s., 1Vrms f.s.
Hioki 3331, 3332- Measure voltage, current, current peak, active/apparent/reactive power, power factor, phase angle, frequency, power integration, current integration
- Model 3331, Volt: 150.00V to 600.00V, Current: 500.00mA to 50.000A, Power: 150.00W to 60.000kW, Frequency 4Hz to 50kHz
- Model 3332, Volt: 15.000V to 600.00V, Current: 1.0000mA to 50.000A, Power: 15.000mW to 30.000kW, Frequency: 1Hz to 100kHz
- Compact and lightweight
Hioki 3333, 3333-01- Measure Voltage, current, active/apparent power, power factor
- Volt: 200.0V(300.0Vmax), Current: 50.00mA to 20.00A(30.00Amax), Power:10.000W to 4.000kW;
Hioki;Power Quality Analyzer;3196, 3197;Sags, Swells, Flicker, Transients, Harmonics, current;
@
Hioki 3196- Measure impulsive voltage quality, RMS voltage, power quality, Three phase quality, harmonic (Up to 50th order) quality, flicker, sags, swells, transients, high frequency transient
- volt ch1 to ch3: 150.00 to 600.00VAC rms, ch4:60.000 to 600.00VAC, 60.000/600.00VDC, Transient overvoltage: 2mega-sampling/sec ch
- Memory capacity: 13MB
Hioki 3197- Measure Implusive volt quality, RMS volt quality, Power quality, Three phase quality, Haromic (Up to 50th order) quality, inrush current, swell, dips, transient over-volt, interruptions, active/reactive energy, demand, load changes, power factor
- Internal memory: 4MB
- Volt range: 600.0VAC, current range:500.0mA/5.000A/50.00A/10.00A/100.0A/500.0A/1.000kA/5.000kA;
Hioki;Pulse Logger;3639-20;Environmental, data logger;
@
Hioki 3639-20- Measure no voltage input connection(eg. switch or relay) counts when contact across terminals changes from short to open
- voltage input: +1.5 to 45V high, 0 to 0.2V low (logic state is undetermined between 0.2 and 1.5V)A count occurs when voltage level becomes high
- Data memory: 32000 data x 1ch;
Hioki;Remote Measurment System;2300 Series;voltage, power, current;
@
Hioki 2300 series- 2301-20 (Humidity module): Temperature 1ch and humidity 1ch, Temperature: -40.0 to 85.0@o@C, Humidity: 0.0 to 100%RH
- 2302-20 (Pt module): Temperature 2ch(Pt100), 2 types of platinum resistance thermo sensors available
- 2303-20 (TC module): 2ch temperature measurement using thermocouples (K,E,J,T). 4 TC types available
- 2304-21 (Pulse module): For 2ch pluse input(volt, contact), max 16M pulses/interval, Input pulse 4kHz max. (volt/electronicontact signal), Input pulse 25Hz max. (mechanical contact signal)
- 2305-20 (Instrumentation module): Voltage/current 2ch measurement, for 4-20mA, 1-5V instrumentation signals
- 2306 (Multi-function module), 2331-20 (Power meter module), 2332-20 (Power meter module), 2341-20 (Input module), 2342-20 (Output module), 2343-20 (RS Link module), 2351-20 (Air module), 2352-20 (wire module), 2353-20 (Lan module), 2354 (Memory module), 2361-20 (AC power module), 2362-20 (DC power module), 2391 Series (Module Base), 2392 (Moduel Base) ;
Hioki;Resistance HiTester;3541;Milliohm Tester, component tester;
@
Hioki 3541- Four-terminal resistance measurement 0.1@m@ohm to 110.000Mohm, Lower power four-terminal resistance measurement 10@m@ohm to 2.00000kohm
- Temperature measurement (Pt) -10.0 to 99.9@o@C (analog) 0 to 2V
- High speed and High precision measurement, as fast as 0.6ms with 70 ppm precision (in 2 kohm to 110 kohm range);
Hioki;Signal Source;7016;current;
@
Hioki 7016- Constant voltage: 0 to @plusminus@ 1.5V, 100 @m@V resolution, 0 to @plusminus@ 15V, 1 mV resolution, Sink/source: @plusminus@25 mA, @plusminus@0.03% setting @plusminus@3 dgt
- Constant current: 0 to @plusminus@25 mA, 1@m@A resolution, Sink/source: @plusminus@12 V, @plusminus@0.03 % setting @plusminus@5 dgt
- Pluse signal generation: 0.5 to 4800Hz, 28 ranges, @plusminus@0.005 % setting @plusminus@0.01 Hz
- DC/AC/AC+DC Voltage: 50mV to 250V, AC/DC/AC+DC Current: 50 to 500mA, Resistance: 500ohm to 50Mohm, Temperature: -40 to 1372@o@C, Frequency: 100Hz to 200kHz;
Hioki;Supper megohm meter;SM-24GN, SM-8213, SM-8215, SM-8216;component tester;
@
Hioki SM-24GN- Voltage: 12-250V DC (8ranges)
- GO/NO determination (Rx) of insulation of Non-measureming objects, contact condition between measureing
- Rapid response: 0.1sec
Hioki SM-8213, SM-8215- Model SM-8213: 5V (2.5 x 10000 to 1 x 10@1@@1@ohm), 10V (5 x 10000 to 2 x 10@1@@1@ohm), 15V (7.5 x 10000 to 3 x 10@1@@1@ohm), 25V ( 1.25 x 100000 to 5 x 10@1@@1@ohm), 50V (2.5 100000 to 1 10@1@@2@ohm), 100V (5 x 100000 to 2 x 10@1@@2@ohm)
- Model SM-8215: 50V (2.5 x 100000 to 1 x 10@1@@2@ohm), 100V(5 x 100000 to 2 x 10@1@@2@ohm), 250V (1.25 x 1000000 to 5 x 10@1@@2@ohm), 500V(2.5 x 1000000 to 1 x 10@1@@3@ohm), 1000V (5 x 1000000 to 2 x 10@1@@3@ohm)
- charge-discharge function
- timer, remote starter, comparator & HV-EN function
Hioki 8216- 10V (5 x 10000 to 2 x 10@1@@1@ohm), 25V (1.25 x 100000 to 5 x 10@1@@1@ohm), 50V (2.5 x 100000 to 1 x 10@1@@2@ohm), 100V (5 x 100000 to 1 x 10@1@@2@ohm), 250V (1.25 x 1000000 to 5 x 10@1@@2@ohm), 500V(2.5 x 1000000 to 1 x 10@1@@3@ohm), 1000V(5 x 1000000 to 1 x 10@1@@3@ohm)
- HV-EN function, charge-discharge function;
Hioki;Tacho HiTester;3403, 3404;Tachometer, rotation, Environmental;
@
Hioki 3403- r/min:*@1@(30.00 o 199.99) range to (20000 to 99990) range, r/s:*@2@(0.5000 to 1.9999)range to (200.0 to 1600.0)range, *@1@r/min=rotation per min, *@2@r/s=rotation per sec
- Distance of 50mm(1.97 in) to 200mm(7.87 in)
Hioki 3404- r/min:*@1@ (30.00 to 199.99)range to (20000 to 99990) range, r/s:*@2@ (0.5000 to 1.9999)range to (200.0 to 1600.0)range, Total: Total rotation counts from 0 to 599999, Period: Measure rotation pulses from 600@m@s to 2sec
- Distance: 50mm (1.97 in) to 200mm (7.87 in);
Hioki;Temperature HiTester;3412-50, 3415-01, 3416-01, 3418, 3441, 3442, 3443, 3444, 3445, 3446-01, 3447-01;Environmental, thermometer;
@
Hioki 3412-50- -50@o@C to 999@o@C, 1@o@C resolution
- Data hold function
Hioki 3415-01, 3416-01, 3418- -50@o@C to 500@o@C, 1@o@C resolution
- Model 3415: Two-beam laser marker
- Model 3415-01,3418: Distance: @nogne@72mm(2.83 in) at 1m(3.28ft)
- Model 3416-01: Distance: @nogne@2.5mm(0.10 in) at 30mm(1.18in)
- Infrared, non-contact
Hioki 3441, 3442- -100@o@C to 1300@o@C(-148@o@F to 2372@o@F), Resolution: 0.1@o@C*@1@ or 1@o@C*@2@
- Compact and weight only 160g, >200hrs of continues operation on a single battery
- Max/Min temperature recording and display
- Model 3442: Waterproof construction
Hioki 3443, 3444, 3445- -50.0@o@C to 500.0@o@C, 0.1@o@C resolution
- Model 3443,3444: @nogne@24mm(0.94 in) at a distance of 1m(3.28ft)
- Model 3445: @nogne@2.5mm(0.10 in) at a distance of 7.3cm(2.87 in)
- Dust/splash proof design
- Model 3443: Date memory function: 130pt of data, memory dump to printer
- Model:3444, 3445: real-time output
Hioki 3446-01, 3447-01- Model 3446-01: -100 to 1000@o@C, resolution: 0.1@o@C(-100 to 300@o@C) or 1@o@C(-100 to 1000@o@C), 1ch
- Model 3447-01: -100 to 300@o@C, Resolution 0.1@o@C, 2ch
- Recording: Time, temperature, item, ID, Comparator test result
- Clock, Buzzer, auto power save function, RS-232C interface, data back-up;
Hioki;Temperature Logger;3632-20, 3633-20, 3650;Environmental, data logger;
@
Hioki 3632-20, 3633-20- -20.0@o@C to 70.0@o@C
- Model 3633-20: -40.0@o@C to 180@o@C(when using the external temperature sensor)
- Data memory: 16000 data (60min interval, total 667 days)
- waterproof, 1 ch
Hioki 3650- -40.0@o@C to 85.0@o@C
- Sensor, memory and battery are all included in one 17.35mm(0.68 in) diameter unit
- Data memory: 2048 data, Max. recording times: Approx. 1 year at 4hr and 15min
- 1 ch;
Hioki;2D Thermo HiTester;3460-50;Environmental, temperature;
@
Hioki 3460-50- -50 to 1000@o@C
- See temperature distribution over 8 x 8 on-screen arrays, Transmission type color TFT liquid crystal
- Transfer data to PC via RS-232C interface;
Hioki;Ultra megohm meter;SM-8220;component tester;
@
Hioki SM-8220- 10V(5 x 10000 to 2 x 100000000000000ohm), 25V(1.25 x 100000 to 5x 100000000000000ohm), 50V(2.5 x 100000 to 1 x 1000000000000000ohm), 100V(5 x 100000 to 2 x 1000000000000000ohm), 250V(1.25 x 1000000 to 5 x 1000000000000000ohm), 500V(2.5 x 1000000 to 1 x 10000000000000000ohm), 1000V(5 x 1000000 to 2 x 10000000000000000ohm)
- Timer, remote starter, comarator & HV-EN function;
Hioki;Voltage Detector ;3120, 3480-21, 3481-22;field;
@
Hioki 3120- AC 70 to 600V, 50/60Hz(when touching insulated wiring equivalent to IV2mm@2@
- Red LED and continuous beeping sound
- DC 3.0V, 170mW(max), 27mW
- CAT IV 600V design
- for 100V Installation
Hioki 3480-21, 3481-22- 90 to 600V AC, 50/60Hz
- Red Flashing LED and beepng buzzer
- CAT IV 600V Safety - Quality in every direction
- Model 3480-21: for 200V Installation
- Model 3481-22: for 100V to 120V Installations;
Hioki;DC Voltage Logger;3635-24/-25/-26, 3645-20;Environmental, data logger;
@
Hioki 3635-24, 3635-25, 3635-26- Model 3635-24: -500.0mV to 500.0mV
- Model 3635-25: -5.000V to 5.000V
- Model 3635-26: -50.00V to 50.00V
- Data memory: 16000data (60min interval, total 667 days)
- Non-volatile memory
Hioki 3645-20- DC @plusminus@50.00mV/@plusminus@500.0mV/@plusminus@5.000V/@plusminus@50.00V
- Data memory: 32000data x 1ch (1min intervla, total 22 days)
- Non-volatile memory
- Preheat signal function;
Hioki;High Voltage Scanner ;3930;field;
@
Hioki 3930- Multi-mode: 4high channels and 4 low channels, Single-mode: 8high channels and a common channel
- AC/DC Raged voltage used: 5kV
- Open/Closed capacity: 50W or 1.0A;
Hioki;(Safety HiTester) Voltage Meter;3258;Multimeters;
@
Hioki 3258- AC Voltage 40 to 66Hz: 30.0V to 420.0V, 380V to 600V
- 600V AC rms
- Data hold function, auto-power save, low battery alarm, non-metallic contact
- Capture the voltage value of covered electric wires, also ideal for metallic busbar and terminals;
Hioki;Wave Comparator;8730-10, 8731-10;Waveform Comparsion, compare;
@
Hioki 8730-10, 8731-10- 100mV to 5V/division, 6 ranges, resolution: 1/160 of range
- DC to 400kH@plusminus@3 dB
- Model 8730-10: Analog 1ch
- Model 8731-10: Analog 2ch
- Memory capacity: 12bits x 50k words/ch, Storage: PC card Type II slot(9726/9727/9728/9729 PC card, 128MB to 1GB);
Hioki;Waveform Generator;7075, 7075-01; ;
@
Hioki 7075, 7075-01- Model 7075: 4ch
- Model 7075-01: 2ch
- Max output voltage: @plusminus@10V o.c.
- 10V range: 10mV to 10V o.c., 1V range: 1mV to 1V o.c., 0.1V range: 0.1mV to 0.1V o.c.
- Min load impedance: 40ohm, Output impedance: 50ohm@plusminus@2% (DC)
- Data storage: FDDx1, MS-DOS format, Waveform memory capacity: 128kW/ch;
Hioki;2-Channel low-frequency characteristics measuring device;DPA-2201;oscillator;
@
Hioki DPA-2201- Oscillator unit: 20Hz - 200kHz
- -70dgm - +20dgm
- Level differential, phase differential measurement functions
- 2ch;
AEMC;4 to 20mA DC current Data Logger;L322;Environmental, Data Logger;
@
AEMC L322- 2 input channel
- 20mA DC with 0.1mA resolution
- Stores up to 240,000 measurements in non-volatile memory
- 3 selectable storage modes ( Stop when full, FIFO, XRM@R@);
AEMC;AC Clamp-On Meter;500, 501;current;
@
AEMC 500, 501- Use for testing distorted currents on UPS, speed controls, static power blocks, chopped power supplies, controllers and motors
- Measure 400AAC, 600VAC
- Measure 400ohm, continuity with beeper below 35ohm
- 42 segment bargraph
- Model 501: Frequency measurement from V and A;
AEMC;AC Current Logger;L101, L102, L111;environment, data logger;
@
AEMC L101- 1 channel, TRMS 0 to 1VAC
- compatible standard current probes with voltage output and BNC connection
- Stores up to 240,000 measurement in non-volatile memory
- 64 samples per cycle
AEMC L102- 2 channel, TRMS 0 to 1VAC
- compatible standard current probes with voltage output and BNC connection
- Stores up to 240,000 measurement in non-volatile memory
- 64 samples per cycle
AEMC L111- 1 channel, TRMS 0 to 1VAC
- compatible standard current probes with current output and banana plug connection
- Stores up to 240,000 measurement in non-volatile memory
- 64 samples per cycle;
AEMC;AC Leakage Current Probes/Meter;2620, AN-1;;
@
AEMC 2620- Differential or leakage current from 500@m@A
- Current up to 400A
- Two switch-selectable measurement ranges: 4AAC / 400AAC
- Large inside jaw diameter
- Work with single-, dual- and three-phase networks
AEMC AN-1- Designed for ungrounded networks, provides intermitten path to ground for leakage current
- Measure 30 to 600VAC
- Switch selectable ground fault cycling of 500mS or 2.3sec
- Four color-coded 5ft 1000V rated leads supplied with alligator clips;
AEMC;AC Line Splitters;ALS-1;current;
@
AEMC ALS-1- Direct reading X1 mode
- Avoids splitting lines, makes reading current easy
- Increase sensitivity of clamp-on probes and clamp-on meter 10 times
- 120V 15A capacity;
AEMC;AC Probe;MD301, MD303, MD304, MD305, MD314, MD315, MN103, MN105, MN106, MN107, MN114, MN115, MN185, MN186, MN170, MN210, MN211, MN212, MN213, MN250, MN251, MN252, MN253, MN254, MN255, MN290, MN291, MN306, MN307, MN312, MN313, MN352, MN353, MN373, MN375, JM845A, JM800A, JM810A, JM813, JM815A, JM250A, JM830A, JM835A, JM840A, JM850A, JM852, JM865A, JM875, SR600, SR601, SR604, SR631, SR632, SR634, SR651, SR652, SR701, SR704, SR751, SR752, SR759;current;Email us for infomation;
AEMC;AC Voltage Logger;L205, L260, L261;environment, data logger, field;
@
AEMC L205, L260- for HVAC, Line voltage, Surge/sag, Stray voltage, Dropout monitoring
- Model L205: 0 to 25Vrms (stray voltage)
- Model L260: 0 to 600Vrms
- Scale automatically selected by software
- Inputs via color-coded safety banana jacks
AEMC L261- Surge and Sag recording, voltage harmonics monitor, find intermittent voltage problem
- TRMS voltage recording up to 600VAC/DC
- 64 samples per cycle
- Stores up to 240,000 measurement in non-volatile memory;
AEMC;AC Voltage/Amp Logger;L562;environment, data logger, field;
@
AEMC L562- Voltage: 0 to 600VAC/DC TRMS
- Current: compatible with current probes with voltage outputs
- Stores up to 240,000 measurement in non-volatile memory
- 64 samples per cycle;
AEMC;AC/DC Clamp-On Meter;503, 511;current;
@
AEMC 503- Power panel, junction box and battery bank monitoring, Electrical testing and troubleshooting
- 400AAC or 400AAC/DC current measurements
- 600VAC/DC volts measurements
- Measure 400ohm, continuity with beeper below 40ohm
AEMC 511- Power panel, junction box and battery bank monitoring, Power plant troubleshooting, AC or DC motor testing
- 1000AAC current measurement
- 750VAC/1000VDC volt measurement
- Measure 400ohm, continuity with beeper below 40ohm
- Frequency measurement from V and A, Diode test;
AEMC;AC/DC Current Probe;MR410, MR411, MR520, MR521, SL201, SL206;;
@
AEMC MR410, MR411, MR520, MR521- Measurement range of 400AAC/600ADC
- Low phase shift for power measurement
- Conforms to EN61010, 600V, Cat.III
- Designed for DMMs, recorders, oscilloscopes, power and harmonic
- Model MR520: Measurement range of 1000AAC/1500ADC
- Model MR521: Measurement range of 100AAC/150ADC & 1000AAC/1500ADC
AEMC SL201, SL206- Low DC and AC measurement
- Model SL201: 50mA to 150ADC/120AAC
- Model SL206: 10mA to 80A
- Design for probing in crowded wiring in industrial and automotive environment
- Hall Effect sensor technology;
AEMC;Cable Tester;CA7024, CA7026, CA7028, TR03;telecommunication, telephone, LAN;
@
AEMC CA7024- Hand-held cable length Meter and Fault Locator
- Detect opens and shorts and distance to them from one end of the cable
- Measure cable length up to 6000ft (2000m)
- Auto cable impedance and compensation
AEMC CA7026- Hand-held Graphical TDR(Time Domain Reflectometer)
- Detect opens and shorts, taps, faulty taps, bridge taps, splitters, high resistance, wet cables, splices..
- Indicates cable faults and terminations up to 11,700ft (3500m)
- Selectable cable impedance (50ohm, 75ohm, 100ohm)
AEMC CA7028- Indicates wiring faults such as split pairs, shorts, opens, reversed pairs and crossed wires
- Graphical and digital display of fault information and length
- Built-in service check function to detect telephone, 10BaseT, 100Mbit+ and token ring
- Identify LAN wiring faults, test patch cords, active service, trace cable location
AEMC TR03- Contains a frequency selective hi-gain, hi-impedance amplifier for clear pick-up
- Compatible with Models CA7024, CA7026, CA7028
- Volume control adjustment
- Locate cable runs, detect breaks in cables, find cables in panels;
AEMC;Carbon Monoxide Meters;CA895;environment, gas detector;
@
AEMC CA895- HVAC installation and maintenance, Subway/tunnel monitoring, Measure CO gas levels in automotive repair facilities
- Two measurement modes: "normal" for detection of CO source and "average" for precise measurement
- "Beeper" indication of possible risk
- MAX and HOLD functions;
AEMC;Circuit Breaker Identifiers;CBI-1;current;
@
AEMC CBI-1- Quick identifies and pinpoints 120VAC circuit breakers and fuses
- Self calibrating - no thumbwheel to adjust
- No need to interrupt power
- Idenify location of circuit breaker, find cross-wired breakers;
AEMC;Clamp-On AC Logger;CL601;current, environment, data logger;
@
AEMC CL601- 0 to 600Arms Input, TRMS measurement
- Overload indication
- Optically isolated USB 2.0 communciation
- 600V Cat. III, 300V Cat. IV;
AEMC;Clamp-On Ground Resistance Testers;3711, 3731;earth tester, field;
@
AEMC 3711, 3731- Use on cell towers, telecommunication sites, pools, spas
- Direct reading of ground resistance from 0.01ohm to 1200ohm
- Direct reading of continuity and ground loop resistance
- Direct reading of ground leakage or phase current from 1mA to 30Arms
- Model 3731: Memory function to store 99 field measurement, alarm function with adjustable set point;
AEMC;Clamp-On Harmonic Meter;721;current, power;
@
AEMC 721- Identify harmonic distortion patterns and sources of voltage harmonics, derating transformers, TRMS voltage and current values
- Designed for traditional and nonlinear loads
- Direct reading %THD, %DF, CF and Peak
- Recording mode for Min, Max, Avg, Max Peak;
AEMC;DC Power Supplies;AX501, AX502, AX503;current;
@
AEMC AX501- For production, Quality assurance, approval agency testing, for educational, repair and calibration labs
- Single output to 30VDC
- Low noise (<1mV Ripple) and stable linear technology for clean output
- High efficiency toroidal transformers
AEMC AX502- For production, Quality assurance, approval agency testing, for educational, repair and calibration labs
- Single and dual 0 to 30VDC / 0 to 2.5A outputs
- Series and Parallel operation permit 0 to 60V or 0 to 5A output
- Low noise (<1mV Ripple) and stable linear technology for clean output
AEMC AX503- For production, Quality assurance, approval agency testing, for educational, repair and calibration labs
- Single, dual and triple 0 to 30VDC / 0 to 2.5A outputs
- Series and Parallel operation permit 0 to 60V or 0 to 5A output
- Low noise (<1mV Ripple) and stable linear technology for clean output;
AEMC;DC Voltage Logger;L410, L432;data logger,environment,field;
@
AEMC L410- Circuit design troubleshooting, Sensor monitoring, Battery testing, Power supply profiling
- Measurement range: 0 to 100mVDC
- Programmable scale, units
- Inputs via color-coded safety banana jacks
AEMC L432- Circuit design troubleshooting, Sensor monitoring, Battery testing, Power supply profiling
- User-selectable ranges: 0 to 100mV, 0 to 1V and 0 to 10VDC per channel
- Programmable storage rates from 8 every second to 1 every day, Mode: when full, FIFO, XRM@R@
- Stores up to 240,000 measurement in non-volatile memory;
AEMC;DC/AC MicroProbes;K100, K110;current;
@
AEMC K100, K110- Industrial process control (4 to 20mA current loops), Automobile wiring, Avionics system/Shipboard maintenance and repair, Pre-deployment testing of power-conscious equipment
- Model K100: Measure extremely low level DC from 100mA
- Model K110: Measure extremely low level DC from 100@m@A
- Outputs signal proportional to total current (DC + AC)
- Low noise, Ultra-compact size;
AEMC;Digital Thermometers;CA861, CA863, CA865;temperature, environmental;
@
AEMC CA861, CA863- Process control monitoring and troubleshooting, HVAC installation and maintenance, Chemical/Food processing
- Use external K thermocouples as temperature sensors
- Measure temperature in @o@F and @o@C
- Model CA861: Measure -40@o@ to 1999@o@F (-40@o@ to 1350@o@C)
- Model CA861: Measure -58@o@ to 1999@o@F (-50@o@ to 1300@o@C)
AEMC CA865- Designed to use an RTD Pt385/100ohm as the temperature sensor for precise temperature measurement
- Measure -58@o@ to 199.9@o@F (-50@o@ to 199.9@o@C)
- Input Protection 24VDC or 24Vrms;
AEMC;Flexible Current Probe;AmpFlex@R@, LongLife AmpFlex@R@,FlexProbe@R@;;Email us for infomation;
AEMC;Flexible Current Probe Logger;AL24-2500;;
@
AEMC AL24-2500- Load profiling, Machine load/Substation monitoring
- Measure 0 to 250Arms, 0 to 2500Arms
- TRMS recording, Record up to 6months
- Weatherproof NEMA4X, IP65 rated;
AEMC;Infrared Thermometer;CA870, CA872, CA876;temperature, environmental;
@
AEMC CA870, CA872, CA876- Model CA870, CA872: -4@o@ to 500@o@F (-20@o@ to 260@o@C)
- Model CA876: -4@o@ to 1022@o@F (-20@o@ to 560@o@C), K thermocouple -40@o@ to 2000@o@F (-40@o@ to 1350@o@C), adjustable emissivity from 0.1 to 1.00
- Model CA872 and CA876: Laser guide for precise aim;
AEMC;Intrinsically Safe Digital Multimeters;MX57EX TRMS;component;
@
AEMC MX57EX TRMS- Oil refineries, Mining, Pharmaceutical plants
- LCI 07: 0010X
- Logic signal measurement and ADP input
- Bargraph with zoom (x5) and center zero
- Measurement Range: 500@m@A/5mA/50mA/500mA (AC/DC), 500mV/5V/50V/500V*/1000V*(AC/DC), 500/5k/50k/500k/5M/50Mohm. Continuity 10ohm to 20ohm, Diode 0 to 2V, 50nF to 50mF, 0.62Hz to 500kHz, -328@o@ to 1472@o@F(-200@o@ to 800@o@C);
AEMC;Lightmeter;CA811, CA813;LUX meter, environmental;
@
AEMC CA811, CA813- Removable sensor for remote reading
- Cosine corrected, CIE photoptic (human eye) response
- Model CA811: 20fc/200fc/2000fc/20kfc, 20lux/200lux/2000lux/20klux
- Model CA813: 20fc/200fc/2000fc/20kfc, 20lux/200lux/2000lux/20klux/200klux;
AEMC;100V Megohmmeters;1039, 1039Kit;component;
@
AEMC 1039- Cable testing, Motor insulation resistance, Dielectric Absorption Ratio and Polarization index measurement
- Test voltage combinations of 50V and 100V
- Insulation measurement 400Mohm, Capacitance measurement to 4000nF
- Cable length measurement to 80.0km(>264,000ft)
AEMC 1039kit- Include 1039 megohmmeter, field case, two color-coded leads, black test probe, remote test probe, MN211 AC current probe, batteries and user manual
- Cable testing, Motor insulation resistance, Dielectric Absorption Ratio and Polarization index measurement;
AEMC;500V Megohmmeters, Part I;1030, 1035, 1035Kit, 1210N;component;
@
AEMC 1030- Motor insulation resistance, Dielectric Absorption Ratio and Polarization Index measurement
- Test voltage of 250V and 500V
- Insulation measurement to 2Gohm
- Continuity with 200mA test current
AEMC 1035- Motor insulation resistance, Dielectric Absorption Ratio and Polarization Index measurement
- Test voltage combination of of 50V, 100V, 250V and 500V
- Insulation measurement to 20Gohm
AEMC 1035 kit- Include 1035 megohmmeter, field case, two color-coded leads, black test probe, remote test probe, batteries and user manual
- Motor insulation resistance, Dielectric Absorption Ratio and Polarization Index measurement, cotinuity checks
AEMC 1210N- Test voltages to 500V
- Insulation measurements to 200Mohm
- Designed for harsh environments: marine, mining, heavy-duty field, industrial and military use
- LED indicates constant voltage output and proper cranked speed;
AEMC;500V Megohmmeters, Part II;1005;component;
@
AEMC 1005- Test voltage to 500V
- Insulation measurement to 1000Mohm
- 0 to 10ohm+ and 0 to 10ohm- continuity range
- Motor (AC and DC), transformer, cables, heater, relay, circuit breaker, rugged construction applications;
AEMC;5000V Megohmmeters;5050, 5060, 5070;component;
@
AEMC 5050, 5060, 5070- Test voltage range 500V(30kohm to 2Tohm), 1000V(1000kohm to 4Tohm), 2500V(100kohm to 10Tohm) and 5000V(300kohm to 10Tohm)
- Adjustable and programmable test voltage 40 to 1000V/1000 to 5100V
- Automatic calculation of DAR, PI and DD values (0.02 to 50.00)
- Measure 0.005 to 49.99@m@F, leakage current at 0.00nA to 3mA
- Model 5050: Stores 20 readings
- Model 5060, 5070: Stores 1500 test results, print direct to printer;
AEMC;Micro-Ohmmeters;6240, 6250;component;
@
AEMC 6240- Ground connections and continuity measurement, motors and small transformers, breakers, switches
- Range: 4000@m@ohm/40mohm/400mohm/4000mohm/40ohm
- Test current range: 10A/1A/100mA/10mA
- Stores up to 99 test results
AEMC 6250- Aerospace metallic coating resistance measurement, winding resistance measurement of motors and transformers, weld joint integrity, earth/ground system verification, cable joint and bus bar connection checks
- Range: 5.0000mohm/25.000mohm/250.00mohm/2500.0mohm/25.000/ohm/250.00ohm/2500.0ohm
- Test current range: 10A/1A/100mA/10mA/1mA
- Stores up to 1500 test result;
AEMC;Moisture Meters;CA847;water instrument, environmental;
@
AEMC CA847- Measure moisture in wood products, plastic, sheetrock and concrete curing
- H2O Measurement Range: 6 to 100%
- Two 20-LED display scales: from 6 to 23% and 24 to 100%
- Replaceable electrodes;
AEMC;Motor / Transformer Testers;DTR-8500;field, phase tester;
@
AEMC DTR-8500- Designed for on-site testing of power, potential and current transformers
- Auto-Ranging: 0.8000 to 1500.0:1
- PT/VT Mode: 44Vrms(max), CT Mode: 0 to 1A Auto Level, 0.1 to 5Vrms
- Display turns ratio, polarity and excitation current simultaneously;
AEMC;Multi-Function Ground Resistance Testers, Part I;6470-B, 6470-B Kit-150ft, 6470-BKit-300ft, 6470-BKit-500ft;Earth tester, field;
@
AEMC 6470-B, AEMC 6470-B Kit 150ft, 6470-B Kit 300ft, 6470-B Kit 500ft- 3-Point/Soil Resistivity 4-point Measurement: 0.01ohm to 99.99kohm
- External Voltage Measurement: 0.1 to 65.0V DC to 450Hz
- Bond Testing for Resistance Measurement: 2-Point (0.01ohm to 99.9kohm)/4Point (0.001ohm to 99.99khom)
- Stores 512 test results
- Model 6470-B Kit 150ft: Includes two 150 ft color-coded leads on spools (red and blue), one 30 ft lead (green), two 14.5 inch T-shaped auxiliary ground electrodes, one set of five spaded lugs, 100ft tape measure and carrying bag
- Model 6470-B Kit 300ft: Includes two 300 ft color-coded leads on spools (red and blue), two 100 ft color-coded leads (green and black), four 14.5 inch T-shaped auxiliary ground electrodes, one set of five spaded lugs, 100ft tape measure and carrying bag
- Model 6470-B Kit 500ft: Includes two 500 ft color-coded leads on spools (red and blue), two 100 ft color-coded leads (green and black), one 30 ft lead(green), four 14.5 inch T-shaped auxiliary ground electrodes, one set of five spaded lugs, 100ft tape measure and carrying bag;
AEMC;Multi-Function Ground Resistance Testers, Part II;6472, 6472Kit-150ft, 6472Kit-300ft, 6472Kit-500ft;Earth tester, field;
@
AEMC 6472, 6472Kit 150ft, 6472Kit 300ft, 6472Kit 500ft- 3-Point Measurement Range: 0.09ohm to 99.9kohm
- Soil Resistivity 4-Point Measurement Auto Range: 0.01 to 99.99kohm Max 999kohm
- External Voltage Measurement: 0.1 to 65.0VAC/DC (DC to 440Hz)
- Bond Testing Resistance Measurement Auto Range: 2-Pole (0.01ohm to 99.9kohm)/ 4-Pole (0.001ohm to 99.99kohm)
- Stores 512 test results
- Model 6472Kit 150ft: Includes two 150 ft color-coded leads on spools (red and blue), one 30 ft lead (green), two 14.5inch T-shaped auxiliary ground electrodes, one set of five spaded lugs, 100 ft tape measure and carrying bag
- Model 6472Kit 300ft: Includes two 300 ft color-coded leads on spools (red and blue), two 100 ft color-coded leads (green and black), four 14.5inch T-shaped auxiliary ground electrodes, one set of five spaded lugs, 100 ft tape measure and carrying bag
- Model 6472Kit 500ft: Includes two 500 ft color-coded leads on spools (red and blue), two 100 ft color-coded leads (green and black), one 30ft lead(green), four 14.5inch T-shaped auxiliary ground electrodes, one set of five spaded lugs, 100 ft tape measure and carrying bag;
AEMC;2000-Count Digital Multimeters;CA5205, MX21;component;
@
AEMC CA5205- Installation, repair or maintenance of industrial equipment, Electrical field testing, troubelshoot failures and poor performance
- AC/DC Voltage 5 Ranges: 200mV to 600V
- Resistance 6 Ranges: 200 ohm to 20Mohm, Continuity: <=700ohm
AEMC MX21- AC Current Range: 200A(w/MN291 clamp)
- AC/DC Voltage Auto Range: 200mV to 600V
- Resistance Range: 200 ohm to 20Mohm, Continuity: < 750ohm;
AEMC;40,000-Count Digital Multimeters;CA5240;component;
@
AEMC CA5240- Installation, repair or maintenance of industrial equipment, Electrical field testing, troubelshoot failures and poor performance
- AC/DC Current 3 Ranges: 40mA to 10A
- AC/DC Voltage 5 Ranges: 400mV to 600V
- Resistance 6 Ranges: 400 ohm to 40Mohm, Continuity: <40ohm
- Capacitance 5 Ranges: 4nF to 40@m@F, Frequency 5 Ranges: 100Hz to 400kHz;
AEMC;4000-Count Digital Multimeters, Part I;CA5210, CA5220, CA5230, CA5260;component;
@
AEMC CA5210- Installation, repair or maintenance of industrial equipment, Electrical field testing, troubelshoot failures and poor performance
- AC/DC Voltage 5 Ranges: 400mV to 600V
- Resistance 6 Ranges: 400 ohm to 40Mohm, Continuity: <40ohm
- Capacitance 5 Ranges: 4nF to 40@m@F
AEMC CA5220, CA5230- Installation, repair or maintenance of industrial equipment, Electrical field testing, troubelshoot failures and poor performance
- AC/DC Current 3 Ranges: 40mA to 10A
- AC/DC Voltage 5 Ranges: 400mV to 600V
- Resistance 6 Ranges: 400 ohm to 40Mohm, Continuity: <40ohm
- Capacitance 5 Ranges: 4nF to 40@m@F
- Model CA5220: Frequency 5 Ranges: 10Hz to 400kHz
- Model CA5230: Frequency 5 Ranges: 100Hz to 400kHz
AEMC CA5260- Installation, repair or maintenance of industrial equipment, Electrical field testing, troubelshoot failures and poor performance
- AC/DC Current 2 Ranges: 400@m@A and 4000@m@A
- AC/DC Voltage 5 Ranges: 400mV to 600V
- Resistance 6 Ranges: 400 ohm to 40Mohm, Continuity: <=35ohm on <400ohm
- Capacitance 3 Ranges: 40@m@F, 400@m@F, 4000@m@F, K thermocouple: -40@o@ to 2000@o@F (-40@o@ to 1000@o@C);
AEMC;4000-Count Digital Multimeters, Part II;MX22;component;
@
AEMC MX22- AC/DC Current Range: 400@m@A to 10A switch selectable
- AC/DC Voltage: 40mV to 600V
- Resistance Range: 400 ohm to 40Mohm, Continuity: < 40ohm
- Frequency: 4kHz to 40MHz;
AEMC;50,000-Count Digital Multimeters;MX55III;component;
@
AEMC MX55III- AC/DC Current Range: 500@m@A to 10A
- AC Voltage: 0.5 to 750V, DC Voltage: 0.5 to 1000V
- Resistance Range: 10 ohm to 20ohm, Continuity: 10 to 20ohm
- Capacitance: 50nF to 50mF, Frequency: 0.62Hz to 500kHz
- dB Function: 10mVAC to 750VAC;
AEMC;5000-Count Digital Multimeters;MX23, MX24B, MX26;component;
@
AEMC MX23- AC Voltage: 0.5 to 750V, DC Voltage: 0.5 to 1000V
- Resistance Range: 500ohm to 50Mohm, Continuity: Below detection of 10 to 20ohm
- Capacitance: 50nF & 50mF, Frequency: 5kHz to 500kHz
AEMC MX24B- AC/DC Current Range: 500@m@A to 10A
- AC Voltage: 0.5 to 750V, DC Voltage: 0.5 to 1000V
- Resistance Range: 500 ohm to 50Mohm, Continuity: Below detection of 10 to 20ohm
- Capacitance: 50nF, 50mF, Frequency: 5kHz to 500kHz
AEMC MX26- AC/DC Current Range: 500@m@A to 10A
- AC Voltage: 0.5 to 750V, DC Voltage: 0.5 to 1000V
- Resistance Range: 500 ohm to 50Mohm, Continuity: Below detection of 10 to 20ohm
- Capacitance: 50nF, 50mF, Frequency: 5kHz to 500kHz;
AEMC;Non-Contact Voltage Detectors;275HVD;field;
@
AEMC 275HVD- Detection of live , residual or induced voltages, Check and detect high voltage cables, Service neon lighting
- Voltage Ranges: 240V/2kV/6kV/11kV/22kV/33kV/132kV/275kV
- Designed for use with hot sticks incorporating a universal spline adaptor
- Audible and visual indication;
AEMC;Oscilloscopes & BNC Terminated Probes, Part I;JM861, MN261, MR461, MR561; ;
@
AEMC JM861- For Electrical utility, HVAC, Plant/industrial maintenance, power quality, Laboratory
- Large jaw window for use on cables and bus bars
- Nominal range: 30A, 300A, 3000A, Current range: 1 to 2400Arms
AEMC MN261- Measurign in breaker panels, HVAC, 5A secondary current transformers monitoring
- Large jaw opening accommodates conductors up to 250MCM
- Designed for DMMs, loggers, recorders and oscilloscopes
- Nominal range: 20A & 200A, Current: 0.1 to 24A/0.5 to 240A
AEMC MR461- For DC motor, Batteries, Automobile engine testing, Power measuring quality analysis, Power load monitoring
- Low phase shift for power measurement
- Design for DMMs, recorders, oscilloscopes, power and harmonic meters
- Nominal Range: 40AAC/60ADC & 400AAC/600ADC
AEMC MR561- For DC motor, Batteries, Automobile engine testing, Power measuring quality analysis, Power load monitoring
- Design for oscilloscopes, waveform displaying instruments and other frequency sensitive displaying instrument with BNC inputs
- Nominal Range: 100AAC/150ADC & 1000AAC/1500ADC;
AEMC;Oscilloscopes & BNC Terminated Probes, Part II;SL261, SR661; ;
@
AEMC SL261- Analysis and measurement of distorted current waveforms and harmonics in industrial or power environments
- Jaw designed for easy maneuvering in crowded spaces
- Nominal Range: 10A & 100A, Current range from 100mA to 100AAC/DC
AEMC SR661- For power quality measuring, Waveform analysis, Power load/Large inustrial load
- Designed for DMMs, recorders, loggers, oscilloscopes, power and harmonic meters
- Large jaw opening accommodates conductors up to two 500MCM
- Nominal Range: 20Apk, 200Apk, 2000Apk;
AEMC;Oscilloscopes;OX 7102-C, OX 7102-C Kit, OX 7104-C, OX 7104-C Power Kit; ;
@
AEMC OX 7102-C, OX 7102-C kit- Five complementary tools in one: Oscilloscope, multimeter, FFT Analyzer, Harmonic Analyzer and Recorder
- Sampling rate 1GS/s in one-shot mode and 25GS/s in ETS - memory depth of 2500-count per channel
- Two isolated channels, 100MHz Bandwidth
- Model OX 7102-C kit: Includes one straight Ethernet cable, SX-METRO data processing and analysis software and one set of two grip probes (red/black)
AEMC OX 7104-C, OX 7104-C Power kit- Five complementary tools in one: Oscilloscope, multimeter, FFT Analyzer, Harmonic Analyzer and Recorder
- Sampling rate 1GS/s in one-shot mode and 25GS/s in ETS - memory depth of 2500-count per channel
- Four isolated channels, 100MHz Bandwidth
- Model OX 7104-C Power kit: Includes OX Power Kit which has two PROBIX PRHX1, 1/10 Probe, 250MHz, 600V Cat III. Two PROBIX 4mm banana plug adapters, three PROBIX current probes (20mA to 80A 100kHz), one PROBIX PRHX7, K thermocouple adapter, three set-of-two color-coded 1.5m leads and clips (red/black 4mm straight, 4mm right angle), small classic tool bag;
AEMC;Outlet GFCI Tester;OT-2;current;
@
AEMC OT-2- Detects faulty wiring in 120V three-wire receptacles
- Detect open ground & neutrals, reversed hot/ground connections
- For use on 100 to 125VAC
- Test GFCI for proper operation;
AEMC;Outlet Tester;OT-1;current;
@
AEMC OT-1- Detects faulty wiring in three-wire receptacles
- Detect open ground & neutrals, reversed hot/ground connections
- For use on 100 to 125VAC;
AEMC;Phase / Motor Rotation Testers;PMR-1, PR-1;field;
@
AEMC PMR-1- Three functions in one unit: Phase rotation tester, Motor rotation tester, Open phase indication
- Fused phase rotation tester Battery operated (motor rotation)
- Input Voltage: 100V to 600VAC max, Frequency Range: 45 to 70Hz
- Motor Rotation Indication: ABC or BAC, Open Phase indication: A,B,C
AEMC PR-1- Identify proper phase sequences, detect missing wire phases, live circuits, proper connection for rotating machinery
- Phase rotation (ABC or BAC) LED indicator
- Bright LED indication of Live or Open Phase (A,B,C)
- Input Voltage: 100 to 600VAC, Frequency: 45 to 70Hz;
AEMC;Resistance Decade Box;BR04, BC05, BR05, BR06, BL07, BR07;field, earth tester;
@
AEMC BR04- Used for testing and calibration of test equipment
- Rotary switch selector
- Four decade ranges from 1 to 10kohm
- Max Current: 20mA
AEMC BC05, BR05- Used for testing and calibration of test equipment
- Rotary switch selector
- Model BR05: Five decade ranges from 1 to 100kohm, Max Current 7mA
- Model BC05: Five decade range from 0.1 to 10@m@F, Total capacitance 11.111@m@F, Residual capacitance 25pF
AEMC BR06- Used for testing and calibration of test equipment
- Rotary switch selector
- Six decade ranges from 1 to 1Mohm
- Max Current: 1mA
AEMC BR07, BL07- Used for testing and calibration of test equipment
- Rotary switch selector
- Model BR07: Seven decade ranges from 1 to 10Mohm, Max Current 0.1mA
- Model BL07: Seven decade ranges from 1@m@H to 10H (11 switch positions), Max DC current 300mA;
AEMC;3-Point Ground Resistance Testers;3620, 3620Kit-150ft, 3620Kit-300ft, 3620Kit-500ft, 3640, 3640Kit-150ft, 3640Kit-300ft, 3640Kit-500ft;Field, Earth Tester;
@
AEMC 3620, 3620Kit-150ft, 3620Kit-300ft, 3620Kit-500ft- For electrical contractors, power utilities, REAs, telephone and CATV
- Range: 0.5 to 1000ohm, test current: 10mA, Resistance Measurement Frequency: 128Hz square wave
- Model 3620 Kit 150ft: Include two 150ft color-coded leads on spools (red and blue), one 30ft lead(green), two 14.5inch T-shaped auxiliary ground electrodes, one set of five fork terminal, 100 ft tape measurer and carrying bag
- Model 3620 Kit 300ft: Include two 300ft color-coded leads on spools (red and blue), two 100ft color-coded leads(green and black), four 14.5inch T-shaped auxiliary ground electrodes, one set of five fork terminal, 100 ft tape measurer and carrying bag
- Model 3620 Kit 500ft: Include two 500ft color-coded leads on spools (red and blue), two 100ft color-coded leads(green and black), one 30ft lead (green), four 14.5inch T-shaped auxiliary ground electrodes, one set of five fork terminal, 100 ft tape measurer and carrying bag
AEMC 3640, 3640Kit-150ft, 3640Kit-300ft, 3640Kit-500ft- Designed to reject high level of interference, maintenance crews performing numerous test
- Range: 20ohm(10mA)/200ohm(1mA)/2kohm(0.1mA), Resistance Measurement Frequency: 128Hz square wave, Open Voltage: <=42V peak
- Model 3640 Kit 150ft: Include two 150ft color-coded leads on spools (red and blue), one 30ft lead(green), two 14.5inch T-shaped auxiliary ground electrodes, one set of five fork terminal, 100 ft tape measurer and carrying bag
- Model 3640 Kit 300ft: Include two 300ft color-coded leads on spools (red and blue), two 100ft color-coded leads(green and black), four 14.5inch T-shaped auxiliary ground electrodes, one set of five fork terminal, 100 ft tape measurer and carrying bag
- Model 3640 Kit 500ft: Include two 500ft color-coded leads on spools (red and blue), two 100ft color-coded leads(green and black), one 30ft lead (green), four 14.5inch T-shaped auxiliary ground electrodes, one set of five fork terminal, 100 ft tape measurer and carrying bag;
AEMC;Sentinel Current Logger;SDL A301, SDL A302, SDL A303, SDL A304, SDL A401, SDL A402;environmental, data logger;
@
AEMC SDL A301, SDL A302, SDL A303, SDL A304- For Load, HVAC monitoring, Energy, Preventative maintenance
- Three channel current recording device
- Stores 480,000 measurements, Programmable from 250ms to 12hr
- Model SDL A301, SDL A303: Current ranges 5 to 1000A
- Model SDL A302, SDL A304: Current ranges 15 to 3000A
AEMC SDL A401, SDL A402- For Load profiling, Engery management, Preventative maintenance, Stray current monitoring
- Four channel current logger recording device
- Stores 480,000 measurement, Programmable from 250ms to 12hrs
- Model SDL A401: Current range 5 to 1000A/15 to 3000A (sensor dependent)
- Model SDL A402: Current Range depend on Probe;
AEMC;Sentinel Voltage Logger;SDL V301, SDL V401;environmental, data logger, field;
@
AEMC SDL V301- For Phase unbalance monitoring, Surge and Sag recording, Line surveys
- Three channel voltage recording device
- Stores 480,000 measurements, Programmable from 250ms to 12hr
- Voltage Range: 0 to 600VAC TRMS, 0 to 850 VDC
AEMC SDL V401- For Phase unbalance monitoring, Surge and Sag recording, Line surveys
- Four channel voltage recording device
- Stores 480,000 measurements, Programmable from 250ms to 12hr
- Voltage Range: 0 to 600VAC TRMS, 0 to 850 VDC;
AEMC;Single-Phase Power Quality Analyzers;8220 (optional with MN93, SR193, Ampflex 193-24, Ampflex 193-36, MR193, MN193), 8230 (Optional with MN93, SR193, AmpFlex 193-24, SR193-36, MR193, MN193);current;
@
AEMC 8220- Motor start-up analysis, Determine phase rotation and motor RPM, Detect hot spots in wiring and equipment
- Voltage (TRMS): Phase to Phase 660V, Phase to Neutral 600V
- Current (TRMS): MN Probe 5mA to 6A/120A or 2 to 240A, MR Probe 10 to 1000AAC/10 to 1400ADC, SR Probe 3 to 1200A, AmpFlex 10 to 6500A
- Measure kW, kVAR, PF, DPF, VA, Phase Rotation Temperature(-320@o@ to 1532@o@F(-200@o@ to 850@o@C)), 6 to 120,000RPM, Resistance, Continuity, Diode Test
- Stores nine sets of readings for volts, amps, power and harmonics
AEMC 8230- Work on single- or three-phase balanced load network, Motor start-up analysis, Verification of pwer distribution circuits
- Voltage(TRMS): Phase to Phase 660V, Phase to Neutral 600V
- Current (TRMS): MN Probe 5mA to 6A/120A or 2 to 240A, MR Probe 10 to 1000AAC/10 to 1400ADC, SR Probe 3 to 1200A, AmpFlex 10 to 6500A
- Measure kW, kVAR, PF, DPF, VA, kVARh, kVAh, K-Factor, Flicker, Harmonic Phase Shift, Phase Rotation, in RUSH
- Stores 1.5MB partitioned for waveforms, alarms and trend recording;
AEMC;Sound Level Meters(Environmental, sound ambiences or nuisances);CA832;noise;
@
AEMC CA832- For Factories, School, Libraries, Airport, Studios, Auditoriums, Hospitals
- Three measurement Range: 35 to 80dB/50 to 100dB/80 to 130dB
- Two time weighting curves: slow(550ms) and fast(55ms)
- Two frequency weighting curves: A and C;
AEMC;Themperature Thermocouple Loggers;L642;environmenta, data logger;
@
AEMC L642- For Process, HVAC, Refrigeration monitoring
- User-selectable thermocouple types J, K, T, N, E, R and S
- Type J: -346 to +2192@o@F (-210 to +1200@o@C), Type K: -348 to +2501@o@F (-200 to +1372@o@C), Type T: -418 to +752@o@F (-250 to +400@o@C), Type N: -328 to +2372@o@F (-200 to +1300@o@C), Type E: -238 to +1742@o@F (-150 to +950@o@C), Type R&S: -32 to +3212@o@F (-0 to +1767@o@C)
- Stores 240,000 measurement (512K);
AEMC;Thermo-Hygrometer;CA846;temperature, environmental;
@
AEMC CA846- Greenhouses, HVAC installation and maintenance, Weather monitoring, Food distribution
- Measure temperature in @o@F and @o@C
- Quick response RH sensor
- MAX and HOLD function
- Measure 4@o@ to 140@o@F (-20@o@ to 60@o@C), 0% to 100%RH;
AEMC;Three-Phase Power Quality Analyzers;3945-B (Optional With MN93, SR193, 24 AmpFlex@R@ 193-24, 36 AmpFlex@R@ 193-36, MR193, MN193);current;
@
AEMC 3945-B- Verification of power distribution circuits, Monitor pad mount transformers, In plant troubleshooting
- Voltage (TRMS): Phase-to-Phase 960V, Phase-to-Neutral 480V
- Current (TRMS): MN Clamp 0 to 6A/120A or 0 to 240A, MR Clamp 0 to 1000AAC/10 to 1400ADC, SR Clamp 0 to 1200A, AmpFlex 0 to 6500A
- Measure DC Voltage Component (15 to 680V), Frequency (40 to 69Hz), kW, kVAR, kVA, PF, DPF, kWH, kVARh, kVAh, Phase Angle (-179@o@ to +180@o@), Harmonics, Total Harmonic Distortion, K-factor, Flicker
- Stores 4MB partitioned for waveforms, transients, alarms and trend recording;
AEMC;TRMS Leakage Current Probes;565;current;
@
AEMC 565- Ground fault current measurement, Process loop, AC monitoring, Medical device safety testing
- Measure 0 to 600mA/10 to 100A (AC TRMS, Auto-Ranging)
- Measure 0 to 600V AC(TRMS)/DC
- Measure 0 to 1kohm;
AEMC;TRMS, AC/DC, Voltage, Hz, Power (kW), Phase Rotation, Ohms Clamp-On Meter;F05, F09;current, component, field;
@
AEMC F05, F09- For Electrical, Safety lighting system, Industrial maintenance, HVAC, Electrical power distribution
- 0.2 to 400Arms AC (Auto-Ranging)
- 0.2 to 600Vrms AC/DC (Auto-Ranging)
- Model F01: 400ohm
- Model F09: 0.2 to 400Arms DC (Auto-Ranging), 40kohm, Diode Test, 20kHz, 5W to 240kW(kW, kVA, kVAR), Power Factor, Phase Rotation, Inrush Current;
AEMC;TRMS, AC/DC Clamp-On Meter;502, 512, 514, F1N, F3N, F01;current;
@
AEMC 502- Power panel, junction box and battery bank monitoring, HVAC, Industrial, commercial and residential troubleshooting
- 0.05 to 400Arms AC (Auto-Ranging)
- 0.5 to 600Vrms AC (Auto-Ranging), 0.2 to 600V DC (Auto-Ranging)
- 0.2 to 400ohm, Continuity < 40ohm
AEMC 512, 514- Power panel, junction box and battery bank monitoring, HVAC, Industrial, commercial, residential, Power plant troubleshooting, AC/DC motor testing
- 0.05A to 1000Arms AC (Auto-Ranging)
- 0.5 to 750Vrms AC (Auto-Ranging), 0.2 to 1000V DC (Auto-Ranging)
- 0.2 to 4kohm, Continuity < 40ohm, Diode test
- Model 514: 1A to 1000A DC
AEMC F1N, F3N- Electrical testing of distorted currents found on UPS, speed controls, static power blocks, chopped power supplies, controllers and motors
- 0.3 to 400Arms (700A for sine wave)
- Frequency: 0.5 to 10kHz
- Model F3N: Records and displays min/max/average values, Peak Measurement range 99.9A/1000A
AEMC F01- Electrial power distribution, HVAC, Safety lighting system maintenance
- 0.2 to 400Arms AC(Auto-Ranging)
- 0.2 to 600Vrms AC/DC (Auto-Ranging)
- 400ohm;
AEMC;TRMS, Voltage, Hz, Ohms, Temperature Clamp-On Meter;F03, F07;field, current;
@
AEMC F03, F07- For Electrical/Safety lighting system/Industrial maintenance, HVAC, Automotive test troubleshooting
- 0.2 to 400Arms AC (Auto-Ranging)
- 0.2 to 600Vrms AC/DC (Auto-Ranging)
- Diode Test, Min/Max/Peak
- Model F03: 4kohm
- Model F07: 0.2 to 400Arms DC/AC+DC (Auto-Ranging), 600Vrms AC+DC (Auto-Ranging), 40kohm, 20kHz;
AEMC;Voltage Tester;NC-1;field, voltage detector;
@
AEMC NC-1- Voltage Sensitivity: 100 to 240VAC
- Frequency: 50/60Hz
- Detection Distance < 5mm
- For indoor use and in accordance with overvoltage 600V Cat. III;
kaise;Alligator Clips;940; ;Email us for infomation;
kaise;Analog Insulation Tester;SK-3000, SK-3002, SK-3003, SK-3010, SK-3012, SK-3013, SK-3016, SK-3320;field;
@
kaise SK-3000, SK-3002, SK-3003- Model SK-3000: 250V/500Mohm, 100V/200Mohm, 0.5 to 500Mohm, 0.1 to 200Mohm
- Model SK-3002: 500V/100Mohm, 250V/50Mohm, 0.1 to 100Mohm, 0.05 to 50Mohm
- Model SK-3003: 1000V/2000Mohm, 500V/1000Mohm, 2 to 2000Mohm, 1 to 1000Mohm
- 0 to 600V AC, Timer, Battery Check
kaise SK-3010, SK-3012, SK-3013, SK-3016- Model SK-3010: 50V/100Mohm, 125V/20Mohm, 0.05to 10Mohm, 0.01 to 20Mohm
- Model SK-3012: 250V/50Mohm, 500V/100Mohm, 0.01 to 50Mohm, 0.05 to 100Mohm
- Model SK-3013: 500V/1000Mohm, 1000V/2000Mohm, 0.5 to 1000Mohm, 1 to 2000Mohm
- Model SK-3016: 500V/100Mohm, 1000V/200Mohm, 0.05 to 100Mohm, 0.1 to 200Mohm, Low ohm and continuity test
- Timer function, Battery Check
kaise SK-3320- 250V/50Mohm, 500V/100Mohm, 100V/2000Mohm
- 0.01 to 50Mohm, 0.05 to 100Mohm, 1 to 2000Mohm
- 0 to 600V AC
- Live Wire Warning, Capacitance Discharge, Timer, Battery check;
kaise;Analog Multimeter Drop Proof Tester;SK-350, SK-352, SK-355;current;
@
kaise SK-350, SK-352, SK-355- Model SK-350: hFE (0~1200) Measurement
- Model SK-352: 12A DC, temperature measurement (-30~+200@o@C)
- Model SK-355: 12A AC/DC, Temperature measurement(-30~+200@o@C)
- 0.3/3/12/30/120/300/1200V DC, 60@m@/3m/30m/600mA DC;
kaise;Analog Multimeter With Holster;KF-20;current;
@
kaise KF-20- 0.3/3/12/30/120/300/1200V DC, 12/30/120/300/1200V AC
- 60@m@/3m/30m/300mA DC
- 5k/500k/5Mohm, -30~+200@o@C with 810-02 probe
- Battery Test: 1.5V/R20P/R14P/R6P, Hi range: 250mA loading, Lo range: 50mA loading;
kaise;Clamp Adapters;660, 870;current;
@
kaise 660- Measure up to 400A AC with Model: SK-6150/6160/6165/6166/6167/6180
- Measure up to 400A DC with Model: 4030, KF-20;
kaise;Digital Clamp Meter for DC only;SK-7830;current;
@
kaise SK-7830- 400mA/40A/200A DC
- Power-On initialize, Zero Adjustment, Difference Measurement, Display hold
- Designed for car maintenance, noise cut clamp core
- IEC-61010-1 (CAT III 300V, CAT I 600V, EMC Test Passed);
kaise;Digital Clamp Meters for AC only;SK-7600, SK-7602, SK-7603, SK-7615, SK-7625, SK-7640;current;
@
kaise SK-7600- 40/200A AC (@plusminus@1.8%rdg@plusminus@5dgt)
- Display hold, pocket size, twist-resistant beaked clamp head
- Conductor dia: 27mm
- IEC-61010-1 (CAT III 300V, EMC Test passed)
kaise SK-7602, SK-7603- Model SK-7602: True RMS
- Model SK-7603: Long Time measurement
- 40/400A AC, 400m/4/40/400/600V DC, 4/40/400/600V AC
- 400/4k/40k/400k/4M/40Mohm
- MAX/MIN/Difference measurement, Rubber-molded rotary switch and trigger
kaise SK-7615, SK-7625- Model SK-7615: 2/20/200/400A AC, Conductor Dia: 26mm
- Model SK-7625: 2/20/200/600A AC, Conductor Dia:42mm
- 2 to 600V AC, 200m/2/20/200/600V DC, 200 to 200k/2M/20Mohm
- Round clamp head
kaise SK-7640- 400/2000A AC, 4/40/400/600V AC, 400m/4/40/400/600V DC
- 400/4k/40k/400k/4M/40Mohm
- TRMS, Auto ranging and range hold, Dust proof, water resistant
- Frequency, Duty cycle, Capacitance, MAX/MIN/Difference
- Conductor Dia: 55m;
kaise;Digital Clamp Meters for AC/DC, part I;SK-7660, SK-7661, SK-7682, SK-7706, SK-7707, SK-7708;current;
@
kaise SK-7660, SK-7661- Model SK-7660: TRMS, Peak hold function
- Model SK-7661: MAX/MIN measurement
- 40/400A AC/DC, 400m/4/40/400/600V DC, 4/40/400/600V AC
- 400/4k/40k/400k/4M/40Mohm, Frequency: 5Hz to 49.99kHz
- Diode Test, Capacitance, Difference, Power-on initialize
kaise SK-7682- 40/400A AC/DC, 400m/4/40/400/600V DC, 4/40/400/600V AC
- TRMS, Peak Hold, Simple switch operation
- MAX/MIN/Difference, Frequency, Duty Cycle
- Conductor Dia: 19mm
kaise SK-7706, SK-7707, SK-7708- 400/2000A AC/DC, Conductor Dia: 55m
- Model SK-7706: 40/400/600V AC/DC, Frequency: 10Hz to 25Hz, Duty Cycle: 1% to 99%, Pulse width: 0.1mS to 100.0mS, 4k/40kohm, Temperature (818 Probe)
- Model SK-7707, SK-7708: 4/40/400/600V AC, 400m/4/40/400/600V DC, 1Hz to 100kHz, Duty cycle: 0.1% to 99.9%, 400/4k/40l/400k/4M/40Mohm
- Model 7708: TRMS, Peakhold;
kaise;Digital Clamp Meters for AC/DC, part II;SK-7718, SK-7719, SK-7720, SK-7722;current;
@
kaise SK-7718, SK-7719- 400/1000A AC/DC, 4/40/400/600V AC, 400m/4/40/400/600V DC, 1Hz to 49.99Hz, Duty Cycle: 10% to 90%, 400/4k/40k/400k/4M/40Mohm
- Model SK-7718: TRMS, Peak Hold
- Model SK-7719: Power-on initialize (auto zero adjustment), Range hold
- MAX/MIN/Difference, Dust proof and Water resistant, Conductor Dia: 35mm
kaise SK-7720, SK-7722- Model SK-7720: 400/650V AC/DC
- Model SK-7722: Analog output terminal connectable to oscilloscope/recorder, 40/250V AC/DC
- 400/1000A AC/DC, 10Hz to 4000Hz, Duty Cycle: 0.0% to 99.9%, Pulse width: 1.0mS to 999.9mS, 4k/20kohm
- -30@o@C to 150@o@C (temperature probe), Peak Hold, MAX/MIN/Diference, Conductor Dia: 36mm;
kaise;Digital Insulation Tester;SK-3500, SK-3502;field;
@
kaise SK-3500, SK-3502- Model SK-3500: 50/125/250/500V DC
- Model SK-3502: 125/250/500/1000V DC
- 20.00/400.0ohm, Open Circuit Volt: 6V or more
- Comparator, Timer, Live Wire/High Voltage Warning, Safety Lock
- Data Memory (up to 100 data), Auto Discharge, Zero-ohm Adjustment, Backlight;
kaise;Digital Multimeter Bench-top;DMM SK-4030;Component, milliohm;
@
kaise SK-4030- 400m/4/40/400/1000V DC, 400m/4/40/400/750V AC
- 400@m@/4m/40m/400m/20A DC/AC, 400/4k/40k/400k/4M/40M ohm
- Center-zero bar graph, Bar graph zoom-up function, best for production line measurement
- Comparator function, MAX/MIN and Difference measurement;
kaise;Digital Multimeter Card-type DMM/Probe Tester;SK-6500, SK-6555, SK6592;component, milliohm;
@
kaise SK-6500- 200m/2/20/200/600V DC, 2/20/200/600V AC
- 200/2k/20k/200k2M/20Mohm
- Compact & light, Gold-plated test lead tips, Large rotary switch
- IEC-61010-1 (CATII 600V, CATIII 300V, EMS test passed)
kaise SK-6555- 400m/4/40/400/600V DC, 4/40/400/600V AC
- 400/4k/40k/400k/4M/40Mohm
- 400 count large LCD, MAX/MIN/Difference measurement
- IEC-61010-1(CATII 600V, CATIII 300V, EMC test passed)
kaise SK-6592- 400m/4/40/400/600V DC, 4/40/400/600V AC
- 400/4k/40k/400k/4M/40Mohm, 50nF to 100@m@F
- Easy to use, MAX/MIN/Difference measurement
- IEC-61010-1 (CAT III 600V, EMC test passed);
kaise;Digital Multimeter Handy-type DMM, part I;SK-6150, SK-6160, SK-6165, SK-6166, SK-6167, SK-6180;component, milliohm;
@
kaise SK-6150- 400m/4/40/400/1000V DC, 400m/4/40/400/750V AC
- 400m/20A DC/AC, 400/4k/40k/400k/4M/40Mohm, 99.99Hz to 999.9kHz
- Large LCD and bar graph, Dust proof and water resistant
- MAX/MIN/Difference measurement
kaise SK-6160, SK-6165- 200m/2/20/200/100V DC, 2/20/200/750V AC
- 20m/200m/20A DC/AC, 200/2k/20k/200k/2M/20Mohm
- Model SK-6165 has extra: 200@m@/2mA AC/DC, display hold
- Large LCD, 500hr continuous operation
kaise SK-6166- 200m/2/20/200/300V DC, 2/20/200/300V AC
- 20m/20A DC/AC, 200/2k/20k/200k/2M/20M ohm
- Suitable for motocycle measurement, RPM measurement
- Current measurement with Clamp Adapter
kaise SK-6167- 2/20/200/300V DC/AC, 30A DC/AC
- 200/2k/20k/200k/2M/20M ohm, open circuit: 0.43V
- RPM, Dwell angle, Temperature, Current measurement with clamp adapter
- Range hold, Display hold;
kaise;Digital Multimeter Handy-type DMM, part II;SK-6180;component, milliohm;
@
kaise SK-6180- 400m/1000m/4/40/400/600V DC/AC, 4/20A DC, 20A AC
- 400/4k/40k/400k/4M/40Mohm, 1.0Hz to 99.99kHz
- Open circuit: 3.3V
- Measure Pulse width, Time, Dwell angle, RPM, Temperature, Current with clamp adapter
- MAX/MIN, Peak hold, Difference, Average, Range hold, Display hold;
kaise;Digital Thermometers;SK-6820, SK-6825;Environmental, temperature;
@
kaise SK-6820- -50@o@C ~ 199.9@o@C (0.1@o@C)
- 1 ch, @o@C and @o@F selectable
- Resistance Bulls (Pt)
- Temperature Coefficient: 2dgt/10@o@C, Sampling Rate: 2times/sec
kaise SK-6825- -50@o@C ~ 199.9@o@C
- 2ch
- Temperature Sensor: Pt 100ohm JIS 1604
- Temperature Coefficient: @plusminus@(0.1%rdg+0.1@o@C)/@o@C, Sampling Rate: 2times/sec;
kaise;Earth Tester;SK-3710;Field;
@
kaise SK-3710- Earth Resistance: 10/100/1000ohm, Earth Voltage: 30V
- Use Deflection method of Voltage Drop System
- Taut-band meter for accurate measurement
- IEC-61010-1, Compliant with EMC directive;
kaise;Leakage Clamp Meters;SK-7810, SK-7815, SK-7820, SK-7825;current;
@
kaise SK-7810, SK-7815- Model SK-7810: Manual Ranging, Analog output terminal, 30m/300m/60A AC
- Model SK-7815: Auto Ranging, AC Voltage measurement, 30m/300m/30/60A AC, 300/600V AC
- Comparator, MAX/MIN, Low Pass Filter
- Conductor Dia: 30mm
kaise SK-7820, SK-7825- Model 7820: Conductor Dia: 24mm
- Model SK-7825: Conductor Dia: 40mm
- 40m/400m/40/100A AC, 400/600V AC
- Vibration Alert Comparator, Low Pass Filter, Display Hold
- 100-hrs continuous measurement (with alkaline cells);
kaise;Line Seperator;880;telecommunication;
@
kaise 880- Separate 2-lines of electrical cord into single line so can measure by clamp meter
- Applicable Model: SK-7600/7602/7603/7615/7625/7640/7660/7661/7720/7722/7718/7719/7706/7707/7708/7810/7820;
kaise;Straight Test Pins;792; ;
@
kaise 792- Extra fine and elastic test pin, 0.5mm diameter
- For narrow point measurement
- Insulation coated bottom
- Applicable Model: SK-6592**, 100-41;
kaise;Temperature Probes;810-02, 818, 818-02;Environment;
@
kaise 810-02- -50@o@C to 250@o@C
- Applicable Model: SK-352/355, KF-20
kaise 818- -50@o@C to 160@o@C
- Applicable Model: SK-7706/7720/7722
kaise 818-20- -50@o@C to 100@o@C
- Applicable Model: SK-6180;
kaise;Test Lead;100-57, 100-63; ;Email us for infomation;
kaise;Test Lead Kit;100-41; ;Email us for infomation;
kaise;Test Lead Set;100-62; ;Email us for infomation;
